Network Switch Trendnet 26-Port Industr. Gigabit L2 Managed PoE+ Rackmount

Τεχνικά Χαρακτηριστικά

• Number of basic switching RJ-45 Ethernet ports
  24
• Basic Switching RJ-45 Ethernet Ports Type
  Gigabit Ethernet (10/100/1000)
• Quantity of SFP module slots
  2
• console port
  RJ-45
• mesh standard
  IEEE 802.1AX,IEEE 802.1D,IEEE 802.1Q,IEEE 802.1ab,IEEE 802.1p,IEEE 802.1w,IEEE 802.1x,IEEE 802.3ab,IEEE 802.3ad,IEEE 802.3af,IEEE 802.3at,IEEE 802.3az,IEEE 802.3 u,IEEE 802.3x
• 10G support
  no
• port mirroring
  yes
• link aggregation
  yes
• MAC address self-learning supported
  yes
• Broadcast Storm Control
  yes
• Spanning Tree Protocol
  yes
• VLAN support
  yes
• Virtual LAN functions
  MAC address-based VLAN,Tagged VLAN
• Number of VLANs
  4094
• MAC address table
  8000 entries
• Routing/Switching Capacity
  52 Gbps
• transfer rate
  38.7 Mpps
• Store and Forward
  yes
• Jumbo frames support
  yes
• jumbo frames
  10000
• Data packet buffer memory
  0.5MB
• DHCP functions
  DHCP Option 82,DHCP relay,DHCP server,DHCP snooping
• access control list
  yes
• IGMP snooping
  yes
• BPDU filtering/protection
  yes
• Queue Scheduling Algorithms
  SP, WFQ, Weighted Round Robin (WRR)
• Supported security algorithms
  SNMP,SNMPv2,SNMPv3,SSH-2
• Multicast support
  yes
• Number of filtered multicast groups
  256
• Rack mount
  yes
• form factor
  1U
• product color
  black
• housing material
  metal
• LED indicators
  yes
• International degree of protection (IP code)
  IP30
• certification
  CE FCC IEC 60068-2-27 IEC 60068-2-32 IEC 60068-2-6
• switch type
  managed
• Quality of Service (QoS) support
  yes
• Web-based management
  yes
• ARP inspection
  yes
• System event log
  yes
• Fanless
  yes
• Mean Time Between Failures (MTBF)
  475352 h
• Quick Start Overview
  yes
• rack mount kit
  yes
• broad
  440mm
• depth
  310mm
• height
  44mm
• Weight
  3.58kg
• operating temperature range
  -40 - 70?
• Operating relative humidity
  0 - 95%
• Power over Ethernet (PoE)
  yes
• Number of Power over Ethernet plus (PoE+) ports
  24
• Power over Ethernet (PoE) voltage
  48 v
• Power over Ethernet (PoE) performance per port
  30W
• Total power Power over Ethernet (PoE)
  685W
• Power consumption (max.)
  705W
• energy conservation properties
  overcurrent, short circuit
