Shuttle XPC slim DB860 Barebone Slim Intel / SO‑DIMM DDR5 / Μαύρο

Περιγραφή

Τεχνικά Χαρακτηριστικά

• Brand
  Shuttle Computer
• Product Line
  XPC slim
• Model
  DB860
• Product Type
  Barebone Mini PC
• Color
  Black
• Chassis Volume
  1.35 litres
• Dimensions (L×W×H)
  190 × 165 × 43 mm
• Chassis Material
  Metal (black finish)
• CPU Socket
  Intel LGA1851
• Supported Processors
  Intel Core Ultra 200 series (Arrow Lake‑S) desktop CPUs, up to 65 W TDP
• Chipset
  Intel B860
• Memory Type
  DDR5‑5600 SO‑DIMM
• Memory Slots
  2 SO‑DIMM
• Maximum Memory
  96 GB (2 × 48 GB)
• M.2 Slots
  1 × M.2 2280 (PCIe 5.0 x4 or SATA), 1 × M.2 2230 (WLAN/BT)
• 2.5" Drive Bay
  1 × 2.5‑inch SATA bay
• Graphics
  Integrated Intel Xe graphics and NPU (depends on CPU)
• Maximum Displays
  Up to 4 independent displays
• Video Outputs
  2 × HDMI, 2 × DisplayPort‑class outputs, 1 × USB‑C (USB4 with DisplayPort)
• USB Ports
  Multiple USB ports (reported: 3 × USB 3.2 Gen2 Type‑A, 4 × USB 3.2 Gen1 Type‑A, 1 × USB 3.2 Gen2 Type‑C/USB4)
• Serial Ports
  2 × RS‑232 (reported)
• Audio
  Audio in/out (line‑in/line‑out)
• Networking
  1 × 2.5GbE LAN, 1 × Gigabit Ethernet
• Wireless
  Optional Wi‑Fi/Bluetooth via M.2 2230 module
• OS Support
  Windows 11
• Power / TDP Support
  Up to 65 W CPU TDP
• Use Case
  Compact high‑performance barebone for productivity, media and AI‑capable workloads
• Weight (approx)
  950 g
• Package Dimensions (approx)
  25 × 20 × 8 cm
• Package Weight (approx)
  2000 g
