Shuttle Barebone slim XH810 με 8GB DDR5 RAM

Περιγραφή

Τεχνικά Χαρακτηριστικά

• Brand
  Shuttle
• Product Name
  Shuttle Barebone slim XH810 including 8GB DDR5 RAM
• SKU
  605769
• MPN
  XH810_Bundle_8GB
• EAN
  4046047104581
• Category
  Barebone mini-PC (XPC slim)
• Chassis Volume
  Approximately 3.5–4 litres
• Chassis Material
  Metal/steel compact chassis
• Chassis Color
  Black
• Dimensions (L×W×H, chassis)
  238 × 200 × 72.5 mm
• Height incl. rubber feet
  Approximately 73.3 mm
• Length incl. thumbscrews
  Approximately 250 mm
• Net Weight
  Approximately 1900 g
• Gross Shipping Weight
  Approximately 3200 g
• CPU Socket
  LGA1851
• Supported CPUs
  Intel Core Ultra 200 Series (Arrow Lake-S), Core Ultra 5/7/9
• Chipset
  Intel H810
• Max Supported CPU Base TDP
  65 W
• Motherboard Form Factor
  Mini-ITX (~17 × 17 cm)
• Cooling
  Integrated active cooling with heat-pipe
• Included Memory
  1 × 8GB DDR5 SO-DIMM (DDR5-5600, 1.1 V)
• Memory Slots
  2 × 262-pin SO-DIMM
• Max Memory Capacity
  96GB (Shuttle Europe) / up to 128GB in some listings
• Memory Mode
  Dual-channel capable
• M.2 Slots
  2 × M.2 2280 (M.2_1: PCIe Gen4×4 NVMe + SATA; M.2_2: PCIe Gen4×2 NVMe + USB3.2 Gen1)
• SATA Ports
  2 × SATA III (6 Gb/s)
• Internal Drive Support
  Up to two 2.5" drives or one 3.5" drive
• Video Outputs
  1 × HDMI 2.1, 1 × HDMI 2.0b, 1 × DisplayPort 1.4a
• Max Displays
  Up to 3 simultaneous displays
• Max Resolution
  Up to 7680 × 4320 @ 60Hz
• USB Ports
  2 × USB 3.2 Gen2, 1 × USB 3.2 Gen1 Type-C, 1 × USB 3.2 Gen1 Type-A, 4 × USB 2.0
• Ethernet
  1 × 2.5 Gigabit Ethernet, 1 × 1 Gigabit Ethernet
• Serial/COM
  Expandable up to 6 COM ports (optional/depending on config)
• Security
  Kensington lock slot on rear panel
• VESA Support
  Included VESA mounting bracket
• Orientation
  Horizontal or vertical placement
• Power Supply
  Retail listings show 120W external adapter (region dependent)
• Included (bundle)
  Chassis, motherboard, cooling assembly, VESA mount, 1 × 8GB DDR5 SO-DIMM, external PSU depending on region
• Not Included (typical)
  CPU, storage drive(s), OS, keyboard, mouse, monitor
