Τροφοδοτικό 650W Cooler Master MWE Bronze 650 V3 230V 24-pin ATX ATX Black

Περιγραφή

Τεχνικά Χαρακτηριστικά

• Compliance certificates
  RCM
• Product colour
  Black
• Fan diameter
  12 cm
• Cooling type
  Active
• Number of fans
  1 fan(s)
• Combined power (+3.3V)
  120 W
• Combined power (-12V)
  3.6 W
• Total power
  650 W
• AC input voltage
  200 - 240 V
• Combined power (+5Vsb)
  15 W
• Power protection features
  Overheating
• Max output current (+5V)
  19 A
• Max output current (+5Vsb)
  3 A
• Efficiency
  88%
• Power Factor Correction (PFC) type
  Active
• Power Good signal delay range
  100 - 150 ms
• AC input frequency
  50/60 Hz
• Combined power (+5V)
  120 W
• Input current
  5 A
• Hold time
  16 ms
• Max output current (+12V)
  54 A
• Combined power (+12V)
  648 W
• Max output current (+3.3V)
  19 A
• Max output current (-12V)
  0.3 A
• Operating temperature (T-T)
  0 - 40 °C
• Width
  150 mm
• Depth
  140 mm
• Height
  86 mm
• Weight
  1.65 kg
• ATX version
  3.1
• 80 PLUS certification
  80 PLUS Bronze
• Mean time between failures (MTBF)
  100000 h
• Bearing technology
  HDB
• Purpose
  PC/Server
• Power supply unit (PSU) form factor
  ATX
• Package height
  110 mm
• Package depth
  245 mm
• Package weight
  2.05 kg
• Package width
  190 mm
• Peripheral (Molex) power connectors (4-pin)
  3
• SATA power cable length
  700 mm
• EPS power connector (8-pin)
  Yes
• Peripheral (Molex) power cable length
  550
• Motherboard power connector
  24-pin ATX
• PCI Express power connectors (6+2 pin)
  4
• Motherboard power cable length
  50 cm
• Number of SATA power connectors
  6
• EPS power connector (4+4 pin)
  Yes
• PCI Express power cable length
  62 cm
• Cabling type
  Non-Modular
• EPS cable length
  67 cm
• Products per master (outer) case
  5 pc(s)
• Master (outer) case length
  570 mm
• Master (outer) cases per pallet (air)
  32 pc(s)
• Master (outer) case height
  215 mm
• Master (outer) case width
  260 mm
