MSI PRO B550M-P WIFI6E (7C95-202R) - Micro-ATX μητρική πλακέτα AM4 B550

Περιγραφή

Τεχνικά Χαρακτηριστικά

• Brand
  MSI
• Model
  PRO B550M-P WIFI6E
• MPN
  7C95-202R
• EAN / Barcode
  4711377453530
• Category
  Mainboard / Motherboard / Micro-ATX
• Form Factor
  Micro-ATX (mATX, 244mm x 244mm)
• Socket
  AMD Socket AM4
• Chipset
  AMD B550
• CPU Support
  AMD Ryzen 5000 Series; Ryzen 5000/4000 G-Series APUs; Ryzen 3000 Series (see vendor CPU compatibility list)
• Memory Type
  DDR4
• Memory Slots
  4 x DIMM
• Maximum Memory
  Up to 128GB
• Memory Speed (OC)
  Up to 4400+ MT/s (OC) as supported
• Memory Channel
  Dual-channel
• PCIe Expansion
  1 x PCIe 4.0 x16, 2 x PCIe 3.0 x1
• M.2 Slots
  2 x M.2 (1 x M.2 Gen4 x4; 1 x M.2 Gen3 x4)
• SATA Ports
  4 x SATA 6Gb/s
• Onboard Graphics Outputs
  HDMI, DisplayPort, VGA (via APU I/O) depending on CPU/APU
• USB (rear + internal)
  Multiple USB 3.2 Gen1 (5Gbps) ports including Type-A and Type-C; USB 2.0 ports (see spec sheet for exact counts)
• LAN
  1 x Gigabit Ethernet (1GbE)
• Wireless
  Wi‑Fi 6E (802.11ax, 2.4/5/6 GHz)
• Bluetooth
  Bluetooth 5.3
• Wireless Module
  Pre-installed in M.2 Key-E slot (support for MU-MIMO RX)
• Audio
  Onboard HD Audio (codec per MSI spec)
• BIOS
  MSI UEFI BIOS with standard PRO-series features
• 4K Display Support
  Supports 4K@60Hz output with compatible CPU/APU
• Color / Aesthetics
  Black themed PCB / business-oriented styling
• Included Accessories
  I/O shield, SATA cables, driver/manual media (varies by region)
• Board Material
  Standard PCB (FR-4)
• Typical Board Dimensions
  Approximately 244 mm x 244 mm (micro-ATX)
• Package Weight (approx.)
  ~1200 g (packed box, approximate)
• Product Weight (approx.)
  ~600 g (board only, approximate)
