Motherboard MSI AMD AM5 MPG B850 EDGE TI WIFI

Περιγραφή

Τεχνικά Χαρακτηριστικά

• CPU
  Supports AMD Ryzen 9000/8000/7000 series desktop processors
• Socket
  Socket AM5
• Memory Type
  DDR5 UDIMM
• Maximum Memory Capacity
  256GB
• Memory Speed
  Up to DDR5 8400+ MT/s (OC) and DDR5 5600 MT/s (JEDEC)
• Audio Codec
  Realtek ALC4080
• Audio Features
  7.1-channel USB high-performance audio, supports up to 32-bit/384 kHz playback
• LAN
  1x Realtek RTL8126 5G LAN
• WIFI
  Wi-Fi 7 module with Bluetooth 5.4, supports MU-MIMO TX/RX, up to 5.8Gbps
• PCIe 5.0 x16
  1x PCIe 5.0 x16 (supports up to x16 from the CPU)
• PCIe 3.0 x16
  1x PCIe 3.0 x16 (operates at x1 mode from the chipset)
• PCIe 4.0 x16
  1x PCIe 4.0 x16 (operates at x4 mode from the chipset)
• M.2 Slots
  2x PCIe 5.0 x4 M.2, 1x PCIe 4.0 x2 M.2, 1x PCIe 4.0 x4 M.2
• Form Factor
  ATX
• Dimensions
  304.8mm x 243.84mm
• Power Connectors
  1x ATX_PWR, 2x CPU_PWR, 1x PCIE_PWR (8-pin)
• VRM Setup
  14+2+1 Duet Rail Power System
• Cooling Design
  Premium thermal design with enlarged heatsink
• USB Ports
  4x USB 2.0 (Rear), 4x USB 2.0 (Front), 1x USB 5Gbps Type A (Rear), 4x USB 5Gbps Type A (Front), 2x USB 10Gbps Type A (Rear), 3x USB 10Gbps Type C (Rear), 1x USB 20Gbps Type C (Front)
• RAID Support
  Supports RAID 0, RAID 1, and RAID 10 for M.2 NVMe devices
• Operating System Support
  Windows 11 64-bit
