Jung 1790RTR Ενθετός Θερμοστάτης Δωματίου με Σύνδεση Αισθητήρα

Περιγραφή

Τεχνικά Χαρακτηριστικά

• Brand
  Albrecht Jung GmbH & Co. KG
• Model / MPN
  1790RTR
• EAN / Barcode
  4011377172050
• Product type
  Room thermostat insert (room temperature regulator insert)
• Installation
  Flush-mounted (under-plaster) - compatible with DIN 49073 flush boxes
• Installation depth
  24 mm
• Rated voltage
  AC 230 V
• Mains frequency
  50/60 Hz
• Switching current
  Up to 16 A (AC1)
• Maximum connected load
  Up to 3,600 W
• Control type
  PWM (pulse-width modulation) or two-point control (on/off)
• Sensor connection
  External NTC sensor (FF NTC recommended)
• Cooling mode
  Supports switching to cooling mode via input
• Overheat protection
  Forced shutdown after 60 minutes
• Stand-by power
  Approx. 0.1 – 0.5 W (depending on cover)
• Ambient temperature range
  -5 to +45 °C
• Electrical connection (single-wire)
  1 x 0.5–4.0 mm² or 2 x 0.5–2.5 mm²
• Electrical connection (stranded without ferrule)
  1 x 0.5–4.0 mm² or 2 x 0.5–2.5 mm²
• Electrical connection (stranded with ferrule)
  1 x 0.5–4.0 mm² or 2 x 0.5–1.5 mm²
• Related accessories
  FF NTC external sensor, TSA230NCWW thermal actuator
• Stand-alone visibility
  Requires matching cover/faceplate (insert only)
• Housing / Material
  Plastic housing (module body) - for combination with JUNG covers
