Jung 1730JE Ένθετο διακόπτη περσίδων (Standard) χωρίς είσοδο δορυφορικής/παράλληλης σύνδεσης

Περιγραφή

Τεχνικά Χαρακτηριστικά

• Brand
  ALBRECHT JUNG GMBH & CO. KG
• Model / MPN
  1730JE
• EAN
  4011377151390
• Product type
  Jalousieeinsatz (blinds/roller-shutter/awning control insert)
• Mounting
  Flush-mounted (Unterputz) — installation in device box to DIN 49073
• Rated voltage
  230 V AC
• Mains frequency
  50/60 Hz
• Ambient temperature
  -5 to +45 °C
• Contact type
  µ (micro)
• Standby power
  max. 0.5 W (retailer listings 0.2–0.5 W)
• Running time
  Approx. 120 s
• Connected motor load
  700 W
• Connection type
  Screw terminals
• Terminal wiring
  Single wire 1×0.5–4.0 mm²; 2×0.5–2.5 mm²; stranded with ferrule up to 1.5 mm²
• Number of buttons
  2
• Operating style
  Rocker (Wippe)
• Mechanically operable
  Yes
• Electronically operable
  No
• Satellite input
  No (standard version without Nebenstelleneingang)
• IP rating
  IP20
• Halogen-free
  Yes
• Fixing method
  Claw and screw (Krallen-/Schraubbefestigung)
• Functions
  Timer support via cover; test mode; ventilation position memory via cover; pole-reversal function (from firmware V01)
• Compatible covers
  Steuertaste Standard, Steuertaste Universal, Timer Standard; JUNG HOME / eNet / KNX RF cover variants
• Package quantity per outer carton
  10 pcs per outer carton
• Outer carton dimensions
  220 × 170 × 87 mm
• Packaged weight (single unit, approx.)
  ~130 g
• Product weight (net)
  ~98 g
