INTG Intel Ethernet Network Adapter X710-T2L 2-θύρες 10GbE RJ45 OCP 3.0 (X710T2LOCPV3G1P)

Περιγραφή

Τεχνικά Χαρακτηριστικά

• Brand
  Intel
• Model / MPN
  X710T2LOCPV3G1P (X710-T2L OCP 3.0)
• SKU
  254819
• EAN / Barcode
  5032037154963
• Product Type
  10GbE Dual-Port OCP 3.0 Network Adapter (NIC)
• Ports
  2
• Port Type / Connector
  RJ45 (10GBASE-T copper)
• Speed
  10 Gbps per port (10GbE), backwards compatible to 1GbE
• Host Interface
  OCP NIC 3.0 (OCP 3.0 form factor)
• PCIe Compatibility
  PCIe 3.0 x8 (host interface family for X710 series)
• Form Factor
  OCP NIC 3.0
• Power / Efficiency
  Energy Efficient Ethernet supported
• Virtualization
  SR-IOV, VMDq, Intel VT-c support
• Overlay / Offloads
  VXLAN, GENEVE (overlay offloads), TCP/UDP/IP checksum offloads
• Packet Acceleration
  DPDK support
• Auto-negotiation
  Supported (10GbE/1GbE)
• Operating Temperature
  0 °C to 55 °C
• Storage Temperature
  -40 °C to 70 °C
• Operating Humidity
  Up to 85% non-condensing
• Storage Humidity
  Up to 90% non-condensing at 35 °C
• PCB Dimensions
  116.61 × 76 mm (referenced OCP 3.0 card PCB dimensions)
• Weight
  134 g (product only)
• Typical Materials
  Printed circuit board (FR4), metal shielding/connectors
• Use Case
  Enterprise, cloud, virtualization, high-performance networking
