Grandstream PoE-Injektor 30W (GS-POE30W-MG)

Περιγραφή

Τεχνικά Χαρακτηριστικά

• Brand
  Grandstream
• Model / MPN
  GS-POE30W-MG
• SKU
  21157077
• EAN
  6947273705710
• MPN
  GS-POE30W-MG
• PoE Standard
  IEEE 802.3af, IEEE 802.3at (PoE+), compatible with 802.3bt
• PoE Output Power
  30.2 W (maximum)
• Output Voltage
  54 VDC (Pins 1,2 + ; Pins 3,6 -)
• Ethernet Port Speed
  2.5 Gbps (2.5 Gigabit Ethernet)
• Ports
  1 × LAN IN (2.5G, data in), 1 × LAN OUT (2.5G, PoE enabled)
• Auto Negotiation
  Yes (10/100/1000/2500 Mbps)
• MDI/MDIX
  Yes (auto-correction)
• Input Voltage
  100–240 VAC, 50/60 Hz
• Built-in Power Adapter
  Yes (integrated AC cable ~1.2 m)
• Dimensions (unit)
  140.55 × 60.3 × 35.4 mm
• Weight (unit)
  175 g
• Package Dimensions
  225 × 130.5 × 46 mm
• Package Weight
  ~350 g
• Operating Temperature
  0°C to 45°C
• Storage Temperature
  -10°C to 60°C
• Humidity
  10% to 90% RH (non-condensing)
• LED Indicators
  Power On: Blue; PoE Load Active: Purple
• Protections
  Overload protection, short-circuit protection
• Compliance & Certifications
  UL/cUL, GS, CB, FCC, CE, RoHS
• Package Contents
  1 × GS-POE30W-MG injector, integrated 1.2 m AC power cable, quick installation guide
