Eaton Tripp Lite NG5POE-M2 — 5-θυρών 2.5Gbps Desktop PoE+ Switch (70W)

Περιγραφή

Τεχνικά Χαρακτηριστικά

• Brand
  Eaton Tripp Lite
• Model / MPN
  NG5POE-M2
• SKU
  577863
• EAN / Barcode
  0037332287168
• Product Type
  Unmanaged Desktop Ethernet Switch
• Ports (copper)
  5 × 2.5GbE RJ45
• PoE Ports
  4 (PoE+)
• SFP / Uplink
  1 × 10Gb SFP+
• PoE Standard
  IEEE 802.3at (PoE+)
• Maximum PoE per Port
  30W
• Total PoE Budget
  70W
• Supported Speeds
  100 Mbps, 1 Gbps, 2.5 Gbps
• Auto-Negotiation
  Yes
• Auto MDI/MDIX
  Yes
• Switching Capacity
  45 Gbps
• Forwarding Rate / Port (full-duplex)
  5 Gbps-equivalent per port
• Energy Efficiency
  IEEE 802.3az Energy Efficient Ethernet
• Power Input
  External AC-to-DC adapter, 100–240V AC in; 55V DC, 1.3A out
• Maximum Consumption (approx.)
  90.2W (max), PoE budget 70W
• Mounting
  Desktop and wall-mountable
• Dimensions (unit)
  160 × 110 × 26 mm (approx.)
• Product Weight (unit)
  ~500 g
• Housing Material
  Metal (retailer listings)
• Color
  Black
• Operating Temperature
  0–40°C (32–104°F)
• Storage Temperature
  -40–70°C (-40–158°F)
• Operating Humidity
  10–90% RH, non-condensing
• Storage Humidity
  5–90% RH, non-condensing
• Management
  Unmanaged (plug-and-play)
• Fan
  Fanless (passive cooling)
• Warranty
  3-year limited worldwide
• Typical Applications
  Small office / home office, wireless AP aggregation, IP cameras, VoIP phones
• Safety / Regulatory
  Standard network device certifications (see datasheet)
