DIGITUS Patch καλώδιο CAT 6A F/FTP Slim 0,30 m γκρι 10 τεμάχια

Περιγραφή

Τεχνικά Χαρακτηριστικά

• Brand
  DIGITUS by ASSMANN
• Model / MPN
  DK-1632-A-003S-10
• SKU
  601044
• EAN / Barcode
  4016032504283
• Pack size
  10 pieces
• Cable category
  CAT 6A
• Shielding
  F/FTP (foil over each pair + overall foil)
• Length
  0.30 m
• Color
  Gray
• Conductor material
  Copper (Cu), AWG 32/7
• Jacket material
  LSZH (low smoke zero halogen)
• Connector
  RJ45 plug on both ends
• Wiring
  EIA/TIA 568B, 1:1 pin assignment
• Data rate
  Up to 10 Gbit/s
• Frequency
  500 MHz
• PoE support
  PoE+ ready
• Outer diameter
  Approximately 3.8 mm (slim design)
• Bending radius
  15 x outer diameter (typical)
• Operating temperature
  -20 °C to +60 °C
• Standards
  ISO/IEC 11801-1; EN 50173; ANSI/TIA 568-C; EN 60603-7-4
• Flame retardancy
  IEC 60332-1
• Smoke emission
  IEC 61034
• Dielectric strength
  AC 500 V for 1 minute (no breakdown)
• Mating cycles
  Approx. 750 cycles
• Typical applications
  10BASE-T, 100BASE-T, 1000BASE-T, 10GBASE-T; data centers; high-density patching
• Package
  DIGITUS polybag
