Cudy GS2024S2 v1 Απροσάρμοστος L2 Switch με 24 Θύρες Gigabit (1Gbps) Ethernet και 4 Θύρες SFP

Περιγραφή

Τεχνικά Χαρακτηριστικά

• Product Type
  Unmanaged (listed)
• Layer
  L2
• Alternate Switch Layer (additional data)
  L2/L3
• PoE
  No
• Ethernet Ports (RJ-45)
  24 Port
• Ethernet Port Speed
  1000 Mbps (Gigabit Ethernet, 10/100/1000)
• SFP Ports
  4 Port
• Installed SFP Modules Quantity
  4
• Switching Capacity (HTML specs)
  56 Gbps
• Switching Capacity (additional data)
  20 Gbit/s
• Forwarding Rate
  14.88 Mpps
• MAC Address Table
  8000 entries
• Packet Buffer Memory
  0.5 MB
• Internal Memory
  128 MB
• Flash Memory
  16 MB
• Memory Type
  DDR-SDRAM
• Jumbo Frames
  9.6 KB
• Number of VLANs
  4096
• VLAN Support
  Yes (IEEE 802.1Q)
• Voice VLAN
  Yes
• Link Aggregation
  Yes
• Port Mirroring
  Yes
• Rate Limiting
  Yes
• QoS Support
  Yes
• Traffic Classification
  Yes
• Spanning Tree Protocol
  Yes
• IGMP Snooping
  Yes
• Multicast Support
  Yes
• DHCP Features
  DHCP server, DHCP Option 82, DHCP snooping
• Authentication
  Port-based authentication
• Authentication Types
  AAA, TACACS+
• SSH/SSL Support
  Yes
• IP-MAC-Port Binding
  Yes
• IP Routing / Static Route
  Yes
• Console Port
  RJ-45
• Basic Switching RJ-45 Ports Quantity
  24
• Gigabit Ethernet (copper) Ports Quantity
  24
• Ethernet LAN Data Rates
  10, 100, 1000 Mbit/s
• Cable Types Supported
  Cat5, Cat3, Cat4
• Fiber Type
  Multi-mode
• Packet Forwarding / Multicast
  Supported
• Flow Control Support
  Yes
• Broadcast Storm Control
  Yes
• MAC Address Auto-learning
  Yes
• MAC Address Auto-aging
  Yes
• Spanning Tree
  Yes
• System Event Log
  Yes
• Web-based Management
  Yes (note: management features conflict with 'Unmanaged' label)
• SSH/SSL
  Yes
• Stackable
  Yes
• Rack Mounting
  Yes (1U)
• Form Factor
  1U
• Product Colour
  Black
• Power Supply Included
  Yes
• Power Source
  AC
• AC Input Voltage
  100 - 240 V
• Operating Temperature
  -10 - 50 °C
• Storage Temperature
  -40 - 70 °C
• Operating Relative Humidity
  10 - 90%
• Storage Relative Humidity
  5 - 90%
• Dimensions (WxDxH)
  440 x 204 x 44 mm
• Product Weight
  2.45 kg
• Package Dimensions (WxDxH)
  500 x 290 x 85 mm
• Package Weight
  3.06 kg
• Console/Management Interfaces
  RJ-45 console, Web management, SSH, IPv6 Telnet
