Chieftec VEGA PPG-750-CW Τροφοδοτικό 750W ATX 3.1 Full-Modular Λευκό

Περιγραφή

Τεχνικά Χαρακτηριστικά

• Brand
  Chieftec
• Model
  Vega PPG-750-CW
• Total Power
  750 W
• Form Factor
  ATX
• ATX Version
  3.1
• 80 PLUS Certification
  80 PLUS Gold
• Modularity
  Full Modular
• Fan Diameter
  135 mm
• Fan Bearing
  FDB (Fluid Dynamic Bearing)
• Cooling Type
  Active
• Illumination
  No
• Color
  White
• Power Factor Correction (PFC)
  Active PFC
• AC Input Voltage
  100 - 240 V
• AC Input Frequency
  50/60 Hz
• +12V Max Output Current
  62.5 A
• +5V Max Output Current
  20 A
• +3.3V Max Output Current
  20 A
• -12V Max Output Current
  0.3 A
• Combined Power (+3.3V & +5V)
  100 W
• Combined Power (+5V)
  100 W
• Total +12V Rail Capacity
  750 W (total unit power on +12V)
• Number of SATA Connectors
  6
• Number of Peripheral (Molex) Connectors
  3
• PCI Express (6+2 pin) Connectors
  4
• PCI Express (12+4 pin) Connectors
  1
• CPU Connector (4+4 pin)
  Yes
• ATX Connector (24-pin / 20+4)
  Yes
• Motherboard Power Cable Length
  60 cm
• CPU Power Cable Length
  65 cm
• PCIe (12+4) Cable Length
  600 mm
• SATA Cable Lengths
  150 mm, 400 mm
• Peripheral (Molex) Cable Lengths
  150 mm, 400 mm
• Protections
  OVP, OPP, OTP, OCP, SCP, UVP, SIP
• Purpose
  PC / Gaming / High-performance systems
• Weight
  1960 g
• Package Weight
  2430 g
• Dimensions (W x D x H)
  150 mm x 150 mm x 85 mm
• Package Dimensions (estimated W x L x H)
  24 cm x 17 cm x 12 cm
