Blackmagic Design UltraStudio Mini Replay 12G (Συσκευή καταγραφής & αναπαραγωγής 12G‑SDI)

Περιγραφή

Τεχνικά Χαρακτηριστικά

• Brand
  Blackmagic Design
• Model
  UltraStudio Mini Replay 12G
• SKU
  274313
• EAN / Barcode
  9338716010435
• MPN
  BM-BDLKULSDZMINREP12G
• Category
  Video rig accessories / I/O interface
• Type
  Capture dock / video capture & playback interface
• Interface
  Thunderbolt (Thunderbolt 4 compatible)
• SDI video input
  1
• SDI video outputs
  2
• SDI fill output
  1 (independent)
• SDI key output
  1 (independent)
• SDI monitoring output
  1 (dedicated)
• Supported SDI rates
  270 Mb/s; 1.5 Gb/s; 3 Gb/s; 6 Gb/s; 12 Gb/s
• Video sampling
  4:2:2; 4:4:4
• Color precision
  RGB 4:4:4 (8/10/12‑bit up to 2160p30); YUV 4:2:2 (8/10‑bit in all formats)
• Color spaces
  Rec. 601; Rec. 709; Rec. 2020
• Supported formats
  SD (525i59.94, 625i50), HD (720p, 1080i, 1080p up to 1080p60), 2K DCI, Ultra HD, DCI 4K (up to 4Kp60 in reseller specs)
• Embedded audio input channels
  16
• Embedded audio output channels
  16
• Audio sample rate
  48 kHz
• Audio bit depth
  24‑bit
• Features
  Supports capture & playback over 12G‑SDI; Fill & key outputs for live graphics/replay; Closed captions & RP188 / SMPTE 12M‑2 metadata support
• OS compatibility
  macOS; Windows; Linux
• Use case
  Live graphics, live replay, broadcast capture & playout
• Physical dimensions
  Not specified by manufacturer
• Product weight
  Not specified by manufacturer
• Package contents
  Device, Thunderbolt cable(s) may be included (varies by reseller)
• Materials & finish
  Compact metal/plastic broadcast enclosure (manufacturer not specific)
