AXIS Δικτυακή Πανοραμική Κάμερα Θόλος Q3839-PVE 180° 29MP

Περιγραφή

Τεχνικά Χαρακτηριστικά

• Brand
  Axis Communications
• Model
  Q3839-PVE
• MPN
  02657-001
• SKU
  21168757
• EAN / GTIN
  7331021081215
• Camera type
  Panoramic multisensor dome (4-sensor, stitched 8K-class image)
• Resolution
  29 MP (up to 7552 × 3776)
• Sensor configuration
  4 × 8.3 MP CMOS sensors
• Sensor size
  1/1.8"
• Pixel size
  2.0 µm
• Lens
  4.6 mm, F1.8, fixed iris
• Field of view (horizontal)
  180°
• Field of view (vertical)
  90°
• Max frame rate
  Up to 30 fps (dependent on resolution and power frequency)
• Shutter speed
  1/8500 s to 1/5 s
• Day/Night
  Yes (automatic IR-cut filter)
• Minimum illumination (color)
  0.1 lux
• Minimum illumination (B/W)
  0.03 lux
• Image enhancement
  Lightfinder 2.0; Forensic WDR; Horizon straightening; Lossless zoom
• Video compression
  H.264 (Baseline/Main/High), H.265, Motion JPEG; Zipstream supported
• On-device processing
  Yes — DLPU (deep learning processing unit) for AI analytics
• SoC
  ARTPEC-8 ×2
• RAM
  4096 MB ×2
• Flash storage
  8192 MB
• Local storage
  microSD card slot (local recording)
• Audio
  Two‑way audio support
• Network interface
  RJ45 Ethernet with PoE+ support; single IP address
• Security
  Axis Edge Vault; FIPS 140-2 Level 2 certified key storage
• Environmental rating
  IP66, IP67 (outdoor ready)
• Vandal rating
  IK10
• Operating temperature range
  -40 °C to 50 °C
• Mechanical adjustment
  Pan ±176°; Tilt 30° to 88°; Roll ±7°
• Dimensions
  270 × 270 × 330 mm
• Product weight
  4380 g
• Country of origin
  Mexico
• Use cases
  Large-area situational awareness, outdoor surveillance, edge analytics, object classification and counting
• Packaging weight (estimated)
  6000 g
• Packaging dimensions (estimated WxLxH cm)
  35×35×40
