ASRock Mainboard W680D4ID-2T/G5/X550 mini-DTX Socket 1700 DDR5-only Single

Περιγραφή

Τεχνικά Χαρακτηριστικά

• Model
  W680D4ID-2T/G5/X550
• Brand
  ASRock Rack
• MPN
  W680D4ID-2T/G5/X550
• SKU
  21294435
• EAN
  4711430523637
• Form Factor
  Deep Mini-ITX (170.18 x 208.28 mm)
• CPU Socket
  LGA 1700 (Single Socket)
• Chipset
  Intel W680
• Supported CPUs
  Intel 12th/13th Gen Core processors and Intel Xeon W-series (LGA1700)
• Memory Type
  DDR5 UDIMM (ECC and Non-ECC supported)
• DIMM Slots
  4
• Maximum Memory
  128 GB (4 x 32 GB)
• Memory Configuration
  Dual Channel, supports UDIMM only (no RDIMM)
• Memory Speeds Supported
  Up to 4400 MT/s (varies by configuration)
• PCIe Slots
  1 x PCIe 5.0 x16 (from CPU)
• M.2 Slots
  1 x M-key (PCIe 4.0 x4, 2280)
• Oculink Ports
  4 x Oculink (PCIe Gen4 x4 or 4x SATA)
• SATA Ports
  4 x SATA 6Gb/s
• LAN
  2 x Intel i210 (1GbE) + 2 x Intel X710 (10GbE Base-T)
• BMC / Remote Management
  ASPEED AST2600 (IPMI)
• Display Outputs
  1 x DisplayPort, 1 x HDMI, 1 x VGA (legacy)
• Serial Port
  1 x COM (serial)
• USB Ports
  Rear: USB 3.2 Gen1 Type-A x2; internal headers for additional USB
• Power Connectors
  1 x 24-pin ATX, 2 x 8-pin CPU
• BIOS / Management Features
  ASRock Rack Instant Flash, IPMI, ACPI 6.4+, SMBIOS 2.8+
• ECC Support
  Yes (ECC UDIMM supported)
• Typical Use
  Compact server/workstation, remote-managed systems
• Weight (board)
  Approximately 700 g
• Boxed Weight
  Approximately 1200 g
• Manufacturer
  ASRock Rack
• Country of Origin
  (not specified)
• Additional Features
  4 x Oculink for high-speed external storage, PCIe 5.0 support, compact server design
