AJA 12G-AMA 4-κανάλιος ισορροπημένος αναλογικός ενσωματωτής/αποσυμπιεστής ήχου για 12G-SDI

Περιγραφή

Τεχνικά Χαρακτηριστικά

• Brand
  AJA Video Systems
• Model
  12G-AMA
• MPN
  12G-AMA
• SKU
  21169435
• EAN
  0812321032260
• Product Type
  4-channel balanced analog audio embedder/disembedder mini-converter
• Primary Application
  Embed/disembed analog audio in 12G-SDI video paths for professional video systems
• Video I/O
  12G-SDI input and output (single-link) supporting up to 4K/UltraHD
• Supported Resolutions
  Up to 4096x2160p60 and 3840x2160p60; SD/HD/2K supported
• Audio I/O
  Balanced analog audio via 1x 25-pin D-Sub (4 in / 4 out) with supplied breakout cable (4x XLR female inputs, 4x XLR male outputs)
• Audio Channels
  4 analog channels; supports pass-through of SDI embedded audio and embedding of analog inputs; up to 16 embedded channels in supported workflows
• Audio Embedding
  User-selectable per channel pair; can pass incoming SDI audio or embed analog input audio from breakout
• Audio Disembedding
  Always-active 4 analog outputs
• Analog Levels
  Selectable analog audio levels
• Control/Configuration
  USB configuration via AJA Mini-Config software and DIP switch setup
• Extras
  HDR pass-through; automatic input video standard detection; 1.5G-SDI internal signal generator for standalone embedder
• Power Input
  +5 to 16 VDC (power supply included)
• Power Consumption
  ~10 W
• Dimensions (W×D×H)
  147.32 x 78.74 x 25.4 mm (5.8" x 3.1" x 1.0")
• Product Weight
  300 g
• Package Contents
  12G-AMA unit, D-Sub breakout cable with XLR connectors, power supply, documentation
• Warranty
  Five-year limited warranty
• Form Factor
  Compact mini-converter for rack/desk installations
• Optional Variants
  OG/fiber models available with single-link fiber I/O (LC/ST) in AJA product family
