ABB SAH/S8.16.7.1 Schalt-/Jalousieaktor, 8-πλ., 16 A, REG

Περιγραφή

Τεχνικά Χαρακτηριστικά

• Brand
  ABB
• Model
  SAH/S8.16.7.1
• MPN
  2CDG110250R0011
• EAN
  4016779066846
• SKU
  21316919
• Device type
  KNX combi switch/shutter actuator (Schalt-/Jalousieaktor)
• Channels / Outputs
  8 independent relay outputs
• Maximum switching current (per channel)
  16 A
• Rated load context
  AC1 (family rated for AC1 operation)
• Bus system
  KNX (TP)
• Mounting type
  DIN rail (REG / Reiheneinbaugerät)
• Protection rating
  IP20
• Dimensions (W x H x D)
  70 x 90 x 63.5 mm
• Module width
  4 TE (4 DIN modules)
• Net weight
  272 g
• Manual operation
  Yes
• Manual operation lock/block
  Yes
• Status indication
  Switching/travel status indication per output
• Relay outputs
  Yes (mechanical relays)
• Typical maximum switching power (per channel)
  up to ~1200 W (reseller specification)
• Housing material
  Plastic (typical DIN-rail electrical enclosure)
• Installation location
  Electrical distribution cabinet / DIN rail
• Standards / Compliance
  DIN EN 60947-4-1 referenced for AC1 operation (cos φ = 0.8)
