Network Switch Netgear GS524UP

Technical Specifications

• Device type
  Switch - 24 ports - unmanaged
• Housing type
  Desktop, rack mountable
• Subtype
  Gigabit Ethernet
• ports
  8 x 10/100/1000 (PoE+) + 16 x 10/100/1000 (PoE++)
• Power over Ethernet (PoE)
  PoE++
• PoE budget
  480W
• Performance
  Non-blocking switchable throughput: 48 Gbps ¦ Forwarding rate (1000 Mpbs): 1,448,000 packets per second ¦ Latency (64-byte packets): 12 µs
• MAC address table size
  8000 entries
• Jumbo frame support
  9216 bytes
• Performance characteristics
  Auto-Negotiation, Auto-Uplink (Auto MDI/MDI-X), 192 KB Packet Buffer, Class of Service (CoS), Metal Housing, DiffServ Code Point (DSCP) Support, 2 Fans, Weighted Round-Robining (WRR)
• Product certifications
  IEEE 802.3at, IEEE 802.3az, IEEE 802.3bt
• Status indicator
  Power, PoE, Link/Activity, Fan
• Interfaces
  24 x 10/100/1000 Base-T RJ-45 16 ports (PoE++)/8 ports (PoE+) - 60W
• Power supply device
  Internal power supply
• Installed number
  1
• Required mains voltage
  AC 100 - 230 V (50/60 Hz)
• Power consumption during operation
  578.8 watts
• Power consumption in standby mode
  24.4 watts
• Accessories included
  Rubber feet
• Rack mount kit
  Supplied
• MTBF
  809853.3 hours
• Product certifications
  Plug and Play, IEC 60950-1, BSMI CNS 14336-1, IEC 62368-1, EN 62368-1 Second Edition, UL 62368-1, EN60950-1 (2nd Edition), AS/NZS 62368.1
• Localization
  Asia Pacific, UK, Europe
• Width
  39cm
• depth
  22cm
• Height
  4.3cm
• Weight
  3.1kg
• Service and support
  Limited Warranty - Lifetime
• Min operating temperature
  0°C
• Max. operating temperature
  50°C
• Permissible humidity during operation
  10 - 90% (non-condensing)
• Min. storage temperature
  -20°C
• Max. storage temperature
  70°C
• Permissible humidity during storage
  10 - 95% (non-condensing)
