Network Switch LevelOne 48x GE GEL-5271 4xGSFP 19"

Technical Specifications

• Number of basic switching RJ-45 Ethernet ports
  48
• Basic Switching RJ-45 Ethernet Ports Type
  Gigabit Ethernet (10/100/1000)
• Number of Gigabit Ethernet (copper) ports
  48
• Number of installed SFP modules
  4
• power plug
  AC input jack
• mesh standard
  IEEE 802.1D, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
• 10G support
  yes
• Copper Ethernet cabling technology
  10BASE-T, 100BASE-TX, 1000BASE-T
• port mirroring
  yes
• Broadcast Storm Control
  yes
• Ethernet LAN data transfer rates
  10,100,1000Mbps
• Ethernet cable cabling technology
  1000BASE-LHX, 1000BASE-LX, 1000BASE-SX, 1000BASE-ZX
• MAC address table
  16000 entries
• Static route
  yes
• Jumbo frames support
  yes
• jumbo frames
  10000
• DHCP functions
  DHCP Option 82, DHCP client, DHCP snooping
• access control list
  yes
• IGMP snooping
  yes
• password protection
  yes
• Multicast support
  yes
• router protocol
  RIP
• Rack mount
  yes
• Stackable
  no
• form factor
  1U
• product color
  Black
• LED indicators
  Activity, Link, Achievement
• country of origin
  China
• certification
  FCC Part 15 Subpart B, CE Mark, EN IEC 62368-1, EN 55032, EN 55035, EN 61000-3-2/3, RoHS
• switch type
  managed
• switch level
  L2+
• Quality of Service (QoS) support
  yes
• Web-based management
  yes
• Built-in processor
  yes
• RAM
  256MB
• Flash memory
  512MB
• noise level
  45dB
• Firmware upgradeable
  yes
• Goods tariff number (HS)
  85176990
• Supplied cables
  AC
• Quick Start Overview
  yes
• rack mount kit
  yes
• packaging type
  box
• packaging width
  535mm
• packing depth
  340mm
• packing height
  80mm
• package weight
  4.2kg
• Broad
  440mm
• depth
  300mm
• Height
  44mm
• weight
  3.5kg
• operating temperatur
  10 - 50 °C
• Storage temperature range
  -40 - 70?
• Operating relative humidity
  10 - 90%
• humidity during storage
  5 - 95%
• Power over Ethernet (PoE)
  no
• energy source
  AC
• Power adapter included
  yes
• AC input voltage
  100 - 240V
• AC input frequency
  50/60Hz
• Power consumption (standard operation)
  40W
