Access Point TP-Link Omada AX5400 Ceiling Mount WiFi 6

Technical Specifications

• Networking standards
  IEEE 802.11ax
• MIMO
  Yes
• Frequency band
  2.4 - 5 GHz
• Ethernet LAN data rates
  2500 Mbit/s
• Maximum data transfer rate
  5400 Mbit/s
• 5 GHz
  Yes
• 2.4 GHz
  Yes
• Automatic channel scanning
  Yes
• VLAN support
  No
• Rate limiting
  Yes
• Maximum data transfer rate (2.4 GHz)
  574 Mbit/s
• Quality of Service (QoS) support
  Yes
• MIMO type
  Multi User MIMO
• Wireless isolation
  Yes
• Number of users
  250 user(s)
• Automatic channel selection
  Yes
• Band steering
  Yes
• Maximum data transfer rate (5 GHz)
  4804 Mbit/s
• Transmitting power (CE)
  <20 dBm(2.4 GHz, EIRP); <23 dBm(5 GHz, band1 & band2, EIRP); <30 dBm(5 GHz, band3, EIRP)
• Transmitting power (FCC)
  <25 dBm (2.4 GHz); <28 dBm (5 GHz)
• BeamForming
  Yes
• 6 GHz
  No
• Reset button
  Yes
• Product colour
  White
• LED indicators
  Yes
• International Protection (IP) code
  IP67
• Placement
  Ceiling, Wall
• Power over Ethernet (PoE)
  Yes
• Input current
  1.5 A
• Number of SSID supported
  16
• Service Set Identifier (SSID) features
  Multiple SSIDs
• Remote Authentication Dial-In User Service (RADIUS)
  Yes
• Access Control List (ACL)
  Yes
• Firmware upgradeable
  Yes
• Web-based management
  Yes
• Depth
  243 mm
• Height
  64 mm
• Width
  243 mm
• Package weight
  1.32 kg
• Package height
  82 mm
• Package depth
  304 mm
• Package width
  302 mm
• Number of products included
  1 pc(s)
• Antenna type
  Internal
• Antenna direction type
  Omni-directional
• Antennas quantity
  6
• Antenna gain level (max)
  5 dBi
• Harmonized System (HS) code
  85176990
