The UNI‑T UT691‑10 Visual Fault Locator is a rechargeable, pen-style fiber optic fault finder and fiber identification tool. Key technical details: 650 ±10 nm visible red laser, ≥10 mW optical output power, continuous and pulse modes, APO (auto power off) default 15 minutes (adjustable), battery:...
More
UNI‑T Visual Fault Locator UT691-10
Product Code: 1167685318
Available in 4 - 10 days
53,18 €
or
1,66€ / month
εως 36 δόσεις με πιστωτική κάρτα
With the purchase of this product you earn 160 Bytes
Quantity:
Add
Need Help? Fill in your details so we can call you immediately!
Έως 36 Δόσεις. Δείτε το πλάνο δόσεων:
TBI Bank
Buy Now Pay Later.
4 installments 0% επιτόκιο, 20€ έως 300€
3 to 60 installments 300€ έως 100.00€
- 1. Ship with ACS Courier
- 2. Αποστολές με μεταφορικές εταιρίες για ογκώδη αντικείμενα
-
3. Pickup from BoxNow automated machine:
Με την BoxNow μπορείς να παραλάβεις το δέμα σου από Αυτόματο Μηχάνημα Παραλαβής που βρίσκεται κοντά σου, όλες τις ώρες της ημέρας 24/7. Η υπηρεσία έχει χρέωση 3€. Υπάρχει δυνατότητα αντικαταβολής με επιπλέον χρέωση 1€.
-
4. Pickup from the store:
Leof. El. Venizelou 73 (former Theseos), Kallithea
Συμπληρώστε τον ταχυδρομικό κωδικό για να λάβετε εκτίμηση τρόπου και κόστους μεταφορικών.
The UNI‑T UT691‑10 Visual Fault Locator is a rechargeable, pen-style fiber optic fault finder and fiber identification tool. Key technical details: 650 ±10 nm visible red laser, ≥10 mW optical output power, continuous and pulse modes, APO (auto power off) default 15 minutes (adjustable), battery: 3.7 V 1050 mAh Li‑polymer (>7 h runtime), charging DC 5 V <1 A, 2.5 mm FC general connector for fiber adapters, LED battery status indicator (4 blue LEDs), built-in LED flashlight, IP54 ingress protection, CE & UKCA certified. Physical size: 130 mm × 38 mm × 27 mm. Typical fiber detection range up to 8–10 km depending on fiber type. Designed for field maintenance of optical cable networks, FTTH, CATV, and sensing applications. SKU/EAN: 6935750569115, MPN: UT691‑10. Images and manufacturer datasheet available from UNI‑T product page and distributor listings.
-
BrandUNI‑T
-
Model/MPNUT691-10
-
Product TypeVisual Fault Locator (VFL) / Fiber optic tester
-
Wavelength650 ±10 nm (visible red)
-
Laser Output Power≥10 mW
-
Emission ModesContinuous mode / Pulse mode
-
Optical RangeApprox. 8–10 km (depending on fiber and conditions)
-
Connector / Adapter2.5 mm FC general connector
-
Battery Type3.7 V 1050 mAh Li‑polymer rechargeable
-
Battery Life>7 hours (typical)
-
ChargingDC 5 V, <1 A (USB charging)
-
Auto Power Off (APO)Default 15 minutes (manually adjustable)
-
Battery Indicator4 blue LEDs (battery status)
-
Additional LightBuilt‑in LED flashlight
-
Durability / ProtectionIP54
-
CertificationsCE, UKCA
-
Dimensions130 mm × 38 mm × 27 mm
-
Weight (device)100 g (approx.)
-
Package Weight200 g (approx.)
-
Housing / DesignErgonomic, non‑slip humanized design
-
Key DurabilityKey press life >5000 times
-
Use CasesOptical fiber fault detection, end‑to‑end fiber identification, field maintenance, CATV
-
Series NotesUT691 series — UT691‑10 is higher‑power variant vs UT691‑01
Ratings
Description
The UNI‑T UT691‑10 Visual Fault Locator is a rechargeable, pen-style fiber optic fault finder and fiber identification tool. Key technical details: 650 ±10 nm visible red laser, ≥10 mW optical output power, continuous and pulse modes, APO (auto power off) default 15 minutes (adjustable), battery: 3.7 V 1050 mAh Li‑polymer (>7 h runtime), charging DC 5 V <1 A, 2.5 mm FC general connector for fiber adapters, LED battery status indicator (4 blue LEDs), built-in LED flashlight, IP54 ingress protection, CE & UKCA certified. Physical size: 130 mm × 38 mm × 27 mm. Typical fiber detection range up to 8–10 km depending on fiber type. Designed for field maintenance of optical cable networks, FTTH, CATV, and sensing applications. SKU/EAN: 6935750569115, MPN: UT691‑10. Images and manufacturer datasheet available from UNI‑T product page and distributor listings.
Technical Specifications
-
BrandUNI‑T
-
Model/MPNUT691-10
-
Product TypeVisual Fault Locator (VFL) / Fiber optic tester
-
Wavelength650 ±10 nm (visible red)
-
Laser Output Power≥10 mW
-
Emission ModesContinuous mode / Pulse mode
-
Optical RangeApprox. 8–10 km (depending on fiber and conditions)
-
Connector / Adapter2.5 mm FC general connector
-
Battery Type3.7 V 1050 mAh Li‑polymer rechargeable
-
Battery Life>7 hours (typical)
-
ChargingDC 5 V, <1 A (USB charging)
-
Auto Power Off (APO)Default 15 minutes (manually adjustable)
-
Battery Indicator4 blue LEDs (battery status)
-
Additional LightBuilt‑in LED flashlight
-
Durability / ProtectionIP54
-
CertificationsCE, UKCA
-
Dimensions130 mm × 38 mm × 27 mm
-
Weight (device)100 g (approx.)
-
Package Weight200 g (approx.)
-
Housing / DesignErgonomic, non‑slip humanized design
-
Key DurabilityKey press life >5000 times
-
Use CasesOptical fiber fault detection, end‑to‑end fiber identification, field maintenance, CATV
-
Series NotesUT691 series — UT691‑10 is higher‑power variant vs UT691‑01
