Τροφοδοτικό 850W Seasonic Core Gx White 80 Plus Gold / Srp-Cgx851-A5A32Sf-W

Description

Technical Specifications

• Efficiency
  80 PLUS Gold certified, with 90% efficiency at 50% system load
• Power Rating
  850W continuous power output
• Form Factor
  ATX 3.1 compliant
• Modularity
  Fully modular design
• Fan Size
  135 mm fluid dynamic bearing fan
• Fan Control
  S3FC technology, operates fanless until 30% load
• Fan Life Expectancy
  50,000 hours at 40°C and 15% to 65% relative humidity
• Dimensions
  140 mm (length) x 150 mm (width) x 86 mm (height)
• Operating Temperature
  0–50°C
• MTBF
  100,000 hours at 25°C
• AC Input Voltage
  100 V - 240 V
• AC Input Current
  11–5.5 A
• AC Input Frequency
  50 Hz - 60 Hz
• +3.3 V Output
  20 A
• +5 V Output
  20 A
• +12 V Output
  70 A
• -12 V Output
  0.3 A
• +5 VSB Output
  3 A
• Protection Features
  Over Power Protection, Over Voltage Protection, Under Voltage Protection, Over Current Protection, Over Temperature Protection, Short Circuit Protection
• Safety Certifications
  cTUVus, TUV, CB, CCC, BSMI, EAC, CE
• Environmental Compliance
  Energy Star, RoHS, WEEE, ErP Lot 6, REACH
