Τροφοδοτικό 500W Deepcool PF700X
εως 36 δόσεις με πιστωτική κάρτα
Need Help? Fill in your details so we can call you immediately!
4 installments 0% επιτόκιο, 20€ έως 300€
3 to 60 installments 300€ έως 100.00€
σε όλη την Ελλάδα
Related Products
Τροφοδοτικό 850W Antec CSK850 PRO EC 80+ Bronze Semi-Modular ATX3.1
Τροφοδοτικό 850W Gigabyte Ud850Gm Pg5 Ice / Atx / 100 - 240Hz/ Gp-Ud850Gmpg5Ice
Τροφοδοτικό 2200W Seasonic Prime Px Atx 3.1 / 80 Plus Platinium / Mtbf 100000 / Prime-Px-2200-Atx30
Τροφοδοτικό 650W Adata Xpg Pylon Ii / Atx 3.1 / 80 Plus Bronze / Mtbf 100000 / Pylon650Iib-Bkceu
Τροφοδοτικό 750W Adata Xpg Pylon Ii / Atx 3.1 / 80 Plus Bronze / Mtbf 100000 / Pylon750Iib-Bkceu
The Deepcool PF700X is a high-performance 700-watt power supply unit (PSU) that stands out in the market. Designed in the ATX12V V2.52 form factor, it offers both efficiency and reliability for various PC systems.
This unit boasts an 80 PLUS Bronze certification, ensuring an efficiency of at least 88% at typical 50% load. The cooling system is enhanced by a 120 mm Hypro bearing fan, which operates quietly while managing optimal thermal conditions.
Key Specifications:
- Total Output Power: 700W
- Input Voltage: 200-240V AC, 5A, 50-60Hz
- Output Rails and Currents:
- +3.3V @ 18A (110W max)
- +5V @ 18A (110W max)
- +12V @ 58.3A (up to 699.6W max)
- -12V @ 0.3A (3.6W max)
- +5VSB @ 3A (15W max)
The PSU features various protective mechanisms such as Over Power Protection (OPP), Over Voltage Protection (OVP), and more. With a mean time between failures (MTBF) of approximately 40,000 hours, this model is built for longevity.
-
Total output power700W
-
Input voltage200-240V AC, 5A, 50-60Hz
-
+3.3V output18A (110W max)
-
+5V output18A (110W max)
-
+12V output58.3A (up to 699.6W max)
-
-12V output0.3A (3.6W max)
-
+5VSB output3A (15W max)
-
Power Good Signal delay100-150 ms
-
Hold-up time≥16 ms at 75% load
-
TopologyActive PFC + DC to DC conversion
-
CapacitorsHigh-quality Taiwanese and Japanese electrolytic capacitors
-
Protection featuresOPP, OVP, OCP, SCP, OTP, UVP
-
Operation temperature range0–40°C
-
MTBF40,000 hours
-
Regulatory certificationsCE, TUV-RH, CCC, RCM, KC, ErP 2014 compliant
-
Warranty3 years limited
Ratings
Description
The Deepcool PF700X is a high-performance 700-watt power supply unit (PSU) that stands out in the market. Designed in the ATX12V V2.52 form factor, it offers both efficiency and reliability for various PC systems.
This unit boasts an 80 PLUS Bronze certification, ensuring an efficiency of at least 88% at typical 50% load. The cooling system is enhanced by a 120 mm Hypro bearing fan, which operates quietly while managing optimal thermal conditions.
Key Specifications:
- Total Output Power: 700W
- Input Voltage: 200-240V AC, 5A, 50-60Hz
- Output Rails and Currents:
- +3.3V @ 18A (110W max)
- +5V @ 18A (110W max)
- +12V @ 58.3A (up to 699.6W max)
- -12V @ 0.3A (3.6W max)
- +5VSB @ 3A (15W max)
The PSU features various protective mechanisms such as Over Power Protection (OPP), Over Voltage Protection (OVP), and more. With a mean time between failures (MTBF) of approximately 40,000 hours, this model is built for longevity.
Technical Specifications
-
Total output power700W
-
Input voltage200-240V AC, 5A, 50-60Hz
-
+3.3V output18A (110W max)
-
+5V output18A (110W max)
-
+12V output58.3A (up to 699.6W max)
-
-12V output0.3A (3.6W max)
-
+5VSB output3A (15W max)
-
Power Good Signal delay100-150 ms
-
Hold-up time≥16 ms at 75% load
-
TopologyActive PFC + DC to DC conversion
-
CapacitorsHigh-quality Taiwanese and Japanese electrolytic capacitors
-
Protection featuresOPP, OVP, OCP, SCP, OTP, UVP
-
Operation temperature range0–40°C
-
MTBF40,000 hours
-
Regulatory certificationsCE, TUV-RH, CCC, RCM, KC, ErP 2014 compliant
-
Warranty3 years limited
