The Digitus DN-81630 is a QSFP28 (Quad Small Form-factor Pluggable 28) optical transceiver module specifically designed for 100 Gigabit Ethernet (100GbE) applications. This advanced module supports the IEEE 802.3bm 100GBASE-SR4 standard, offering numerous advantages for modern networking.
One of the key features of the DN-81630 is its four-channel, full-duplex design, which enables an impressive data throughput. Each channel supports up to 26 Gbps, resulting in an aggregate bandwidth of 104 Gbps.
- Data Rate: 100 Gigabits per second aggregated over 4 channels (4 x 26 Gbps)
- Form Factor: QSFP28 pluggable transceiver module
- Optical Technology: Utilizes a VCSEL laser array operating at an 850 nm wavelength
- Transmission Distance: Supports distances of up to 70 meters on OM3 multimode fiber and 100 meters on OM4 multimode fiber
- Power Consumption: Operates with low power usage, less than 3.5 watts
Additionally, this module is compatible with various connectors such as MPO/MT ferrule, enhancing its usability in complex networking environments. The operating temperature range is from 0°C to +70°C, making it versatile for various applications.
This product is ideal for settings that demand high-density data transmission, such as data centers and telecommunications. Its compliance with industry standards ensures reliability and optimal performance.
-
Data Rate100 Gbps
-
Form FactorQSFP28
-
Optical TechnologyVCSEL array, 850 nm
-
Transmission Distance OM370 m
-
Transmission Distance OM4100 m
-
Connector TypeMPO/MT ferrule
-
Power Consumption< 3.5 W
-
Operating Temperature Range0°C to 70°C
Ratings
Description
The Digitus DN-81630 is a QSFP28 (Quad Small Form-factor Pluggable 28) optical transceiver module specifically designed for 100 Gigabit Ethernet (100GbE) applications. This advanced module supports the IEEE 802.3bm 100GBASE-SR4 standard, offering numerous advantages for modern networking.
One of the key features of the DN-81630 is its four-channel, full-duplex design, which enables an impressive data throughput. Each channel supports up to 26 Gbps, resulting in an aggregate bandwidth of 104 Gbps.
- Data Rate: 100 Gigabits per second aggregated over 4 channels (4 x 26 Gbps)
- Form Factor: QSFP28 pluggable transceiver module
- Optical Technology: Utilizes a VCSEL laser array operating at an 850 nm wavelength
- Transmission Distance: Supports distances of up to 70 meters on OM3 multimode fiber and 100 meters on OM4 multimode fiber
- Power Consumption: Operates with low power usage, less than 3.5 watts
Additionally, this module is compatible with various connectors such as MPO/MT ferrule, enhancing its usability in complex networking environments. The operating temperature range is from 0°C to +70°C, making it versatile for various applications.
This product is ideal for settings that demand high-density data transmission, such as data centers and telecommunications. Its compliance with industry standards ensures reliability and optimal performance.
Technical Specifications
-
Data Rate100 Gbps
-
Form FactorQSFP28
-
Optical TechnologyVCSEL array, 850 nm
-
Transmission Distance OM370 m
-
Transmission Distance OM4100 m
-
Connector TypeMPO/MT ferrule
-
Power Consumption< 3.5 W
-
Operating Temperature Range0°C to 70°C
