The Teltonika SWM280 is a 24-port managed Gigabit Ethernet PoE+ switch designed for industrial and enterprise deployments. It provides 12 × Gigabit PoE+ RJ45 ports (802.3af/at) and 12 × Gigabit RJ45 ports, plus 4 × SFP fiber slots (total 28 physical interfaces). The switch supports L2 management...
More
Teltonika SWM280 24-Port Gigabit Managed PoE+ Switch — 12x GbE PoE, 12x GbE, 4x SFP, 300W PoE Budget
Product Code: 1173700902
Available in 4 - 6 days
465,26 €
or
14,53€ / month
εως 36 δόσεις με πιστωτική κάρτα
With the purchase of this product you earn 1396 Bytes
Quantity:
Add
Need Help? Fill in your details so we can call you immediately!
Έως 36 Δόσεις. Δείτε το πλάνο δόσεων:
TBI Bank
Buy Now Pay Later.
4 installments 0% επιτόκιο, 20€ έως 300€
3 to 60 installments 300€ έως 100.00€
- 1. Ship with ACS Courier
- 2. Αποστολές με μεταφορικές εταιρίες για ογκώδη αντικείμενα
-
3. Pickup from BoxNow automated machine:
Με την BoxNow μπορείς να παραλάβεις το δέμα σου από Αυτόματο Μηχάνημα Παραλαβής που βρίσκεται κοντά σου, όλες τις ώρες της ημέρας 24/7. Η υπηρεσία έχει χρέωση 3€. Υπάρχει δυνατότητα αντικαταβολής με επιπλέον χρέωση 1€.
-
4. Pickup from the store:
Leof. El. Venizelou 73 (former Theseos), Kallithea
Συμπληρώστε τον ταχυδρομικό κωδικό για να λάβετε εκτίμηση τρόπου και κόστους μεταφορικών.
The Teltonika SWM280 is a 24-port managed Gigabit Ethernet PoE+ switch designed for industrial and enterprise deployments. It provides 12 × Gigabit PoE+ RJ45 ports (802.3af/at) and 12 × Gigabit RJ45 ports, plus 4 × SFP fiber slots (total 28 physical interfaces). The switch supports L2 management with L3 features, advanced VLAN and routing capabilities, industrial protocols (PROFINET, EtherNet/IP, MRP), a 300 W total PoE budget (up to 30 W per port), 56 Gbps switching capacity, 83.33 Mpps forwarding rate, 8K MAC table, 512 KB packet buffer, jumbo frames up to 10,000 bytes, rack-mount (19"), IP30 aluminum housing, and 100–240 VAC (C14) power input. Teltonika often ships the SWM280 with 2 years RMS remote management included.
-
BrandTeltonika
-
ModelSWM280
-
MPNSWM280000000
-
SKU21169386
-
EAN4779051844074
-
Product TypeManaged Gigabit PoE+ Ethernet Switch (L2 with L3 features)
-
Ports (RJ45)24 x 10/100/1000 Mbps (12 PoE+ enabled)
-
PoE Ports12 x Gigabit PoE+ (802.3af / 802.3at)
-
SFP Ports4 x SFP fiber ports
-
Total Physical Interfaces28 (24 RJ45 + 4 SFP)
-
PoE Budget300 W total
-
PoE per PortUp to 30 W per PoE port
-
Power Input100–240 VAC, 50/60 Hz (C14 connector)
-
Power Consumption (Idle)~7.5 W (per listing)
-
Power Consumption (Max)~325 W (including PoE)
-
Switching Capacity56 Gbps
-
Forwarding Rate83.33 Mpps
-
MAC Address Table8K entries
-
Packet Buffer512 KB
-
Jumbo FramesUp to 10,000 bytes
-
ManagementL2 managed with L3 features; VLAN, routing features, RMS compatible
-
Industrial ProtocolsPROFINET, EtherNet/IP, MRP (per listings)
-
Advanced RoutingOSPF/BGP support mentioned for SWM28 series (model-dependent)
-
Form Factor19" rack-mount
-
Dimensions (device)483 × 44 × 234 mm
-
Housing MaterialAnodized aluminum housing and panels
-
Ingress ProtectionIP30
-
Operating Temperature0 °C to 50 °C
-
Operating Humidity10% to 90% non-condensing
-
Included ServicesTypically includes 2 years Teltonika RMS (per reseller listings)
-
MountingRack-mount ears included (19")
-
Connector FeaturesAuto MDI/MDIX
-
Ethernet StandardsIEEE 802.3i, 802.3u, 802.3ab, 802.3x, 802.3az
-
Use CasesIndustrial automation, enterprise, EV charging infrastructure, smart cities, campus networks
-
MSRP/Packaging ContentsSwitch unit, mounting brackets/ears, quick start (power cord sold separately in some listings)
Ratings
Description
The Teltonika SWM280 is a 24-port managed Gigabit Ethernet PoE+ switch designed for industrial and enterprise deployments. It provides 12 × Gigabit PoE+ RJ45 ports (802.3af/at) and 12 × Gigabit RJ45 ports, plus 4 × SFP fiber slots (total 28 physical interfaces). The switch supports L2 management with L3 features, advanced VLAN and routing capabilities, industrial protocols (PROFINET, EtherNet/IP, MRP), a 300 W total PoE budget (up to 30 W per port), 56 Gbps switching capacity, 83.33 Mpps forwarding rate, 8K MAC table, 512 KB packet buffer, jumbo frames up to 10,000 bytes, rack-mount (19"), IP30 aluminum housing, and 100–240 VAC (C14) power input. Teltonika often ships the SWM280 with 2 years RMS remote management included.
Technical Specifications
-
BrandTeltonika
-
ModelSWM280
-
MPNSWM280000000
-
SKU21169386
-
EAN4779051844074
-
Product TypeManaged Gigabit PoE+ Ethernet Switch (L2 with L3 features)
-
Ports (RJ45)24 x 10/100/1000 Mbps (12 PoE+ enabled)
-
PoE Ports12 x Gigabit PoE+ (802.3af / 802.3at)
-
SFP Ports4 x SFP fiber ports
-
Total Physical Interfaces28 (24 RJ45 + 4 SFP)
-
PoE Budget300 W total
-
PoE per PortUp to 30 W per PoE port
-
Power Input100–240 VAC, 50/60 Hz (C14 connector)
-
Power Consumption (Idle)~7.5 W (per listing)
-
Power Consumption (Max)~325 W (including PoE)
-
Switching Capacity56 Gbps
-
Forwarding Rate83.33 Mpps
-
MAC Address Table8K entries
-
Packet Buffer512 KB
-
Jumbo FramesUp to 10,000 bytes
-
ManagementL2 managed with L3 features; VLAN, routing features, RMS compatible
-
Industrial ProtocolsPROFINET, EtherNet/IP, MRP (per listings)
-
Advanced RoutingOSPF/BGP support mentioned for SWM28 series (model-dependent)
-
Form Factor19" rack-mount
-
Dimensions (device)483 × 44 × 234 mm
-
Housing MaterialAnodized aluminum housing and panels
-
Ingress ProtectionIP30
-
Operating Temperature0 °C to 50 °C
-
Operating Humidity10% to 90% non-condensing
-
Included ServicesTypically includes 2 years Teltonika RMS (per reseller listings)
-
MountingRack-mount ears included (19")
-
Connector FeaturesAuto MDI/MDIX
-
Ethernet StandardsIEEE 802.3i, 802.3u, 802.3ab, 802.3x, 802.3az
-
Use CasesIndustrial automation, enterprise, EV charging infrastructure, smart cities, campus networks
-
MSRP/Packaging ContentsSwitch unit, mounting brackets/ears, quick start (power cord sold separately in some listings)
