The Teltonika PR321NP0 is a compact DIN-rail AC/DC power supply delivering 15 W at a 24 VDC output. Input range is 90–264 VAC (47–63 Hz), with 0.63 A max output current and inrush current up to 45 A. It includes short-circuit protection and 3 kVAC primary-to-secondary isolation. Mechanical mounting...
More
Teltonika DIN Rail Power Supply, 15 W, 24 V (PR321NP0)
Product Code: 1173700866
Available in 4 - 6 days
23,47 €
With the purchase of this product you earn 71 Bytes
Quantity:
Add
Need Help? Fill in your details so we can call you immediately!
TBI Bank
Buy Now Pay Later.
4 installments 0% επιτόκιο, 20€ έως 300€
3 to 60 installments 300€ έως 100.00€
- 1. Ship with ACS Courier
- 2. Αποστολές με μεταφορικές εταιρίες για ογκώδη αντικείμενα
-
3. Pickup from BoxNow automated machine:
Με την BoxNow μπορείς να παραλάβεις το δέμα σου από Αυτόματο Μηχάνημα Παραλαβής που βρίσκεται κοντά σου, όλες τις ώρες της ημέρας 24/7. Η υπηρεσία έχει χρέωση 3€. Υπάρχει δυνατότητα αντικαταβολής με επιπλέον χρέωση 1€.
-
4. Pickup from the store:
Leof. El. Venizelou 73 (former Theseos), Kallithea
Συμπληρώστε τον ταχυδρομικό κωδικό για να λάβετε εκτίμηση τρόπου και κόστους μεταφορικών.
The Teltonika PR321NP0 is a compact DIN-rail AC/DC power supply delivering 15 W at a 24 VDC output. Input range is 90–264 VAC (47–63 Hz), with 0.63 A max output current and inrush current up to 45 A. It includes short-circuit protection and 3 kVAC primary-to-secondary isolation. Mechanical mounting is DIN-rail; both input and output use screw terminals. Dimensions: 90 × 18 × 58 mm. Typical weight: 78 g. Certified to EN 62368-1 and relevant EMC standards. Commonly used to power Teltonika TRB and TSW series devices.
-
BrandTeltonika
-
Model / MPNPR321NP0
-
Product TypeDIN rail AC/DC power supply
-
Power Rating15 W
-
Output Voltage24 VDC
-
Output Current0.63 A (max)
-
Input Voltage Range90–264 VAC (absolute max 85–264 VAC)
-
Input Frequency50/60 Hz (47–63 Hz absolute max)
-
Input Current0.5 A
-
Inrush Current45 A
-
Short-circuit ProtectionYes
-
Isolation Voltage3 kVAC primary-to-secondary
-
MountingDIN rail
-
Input ConnectorScrew terminal
-
Output ConnectorScrew terminal
-
Dimensions (WxDxH)18 × 90 × 58 mm (listed as 90 × 18 × 58 mm)
-
Weight78 g
-
Material / EnclosureMetal/plastic DIN-rail housing (industrial compact form)
-
CertificationsEN 62368-1; EN 55032; EN 55035; EN IEC 61000-3-2; EN 61000-3-3
-
CompatibilityTeltonika TRB245, TRB246, TRB255, TRB256, TSW010, TSW114, TSW210, TSW304
-
Typical ApplicationsIndustrial IoT devices, routers, switches, DIN-rail installations
-
PackagingSmall retail box (estimated dimensions 10 × 4 × 7 cm), protective inner padding
Ratings
Description
The Teltonika PR321NP0 is a compact DIN-rail AC/DC power supply delivering 15 W at a 24 VDC output. Input range is 90–264 VAC (47–63 Hz), with 0.63 A max output current and inrush current up to 45 A. It includes short-circuit protection and 3 kVAC primary-to-secondary isolation. Mechanical mounting is DIN-rail; both input and output use screw terminals. Dimensions: 90 × 18 × 58 mm. Typical weight: 78 g. Certified to EN 62368-1 and relevant EMC standards. Commonly used to power Teltonika TRB and TSW series devices.
Technical Specifications
-
BrandTeltonika
-
Model / MPNPR321NP0
-
Product TypeDIN rail AC/DC power supply
-
Power Rating15 W
-
Output Voltage24 VDC
-
Output Current0.63 A (max)
-
Input Voltage Range90–264 VAC (absolute max 85–264 VAC)
-
Input Frequency50/60 Hz (47–63 Hz absolute max)
-
Input Current0.5 A
-
Inrush Current45 A
-
Short-circuit ProtectionYes
-
Isolation Voltage3 kVAC primary-to-secondary
-
MountingDIN rail
-
Input ConnectorScrew terminal
-
Output ConnectorScrew terminal
-
Dimensions (WxDxH)18 × 90 × 58 mm (listed as 90 × 18 × 58 mm)
-
Weight78 g
-
Material / EnclosureMetal/plastic DIN-rail housing (industrial compact form)
-
CertificationsEN 62368-1; EN 55032; EN 55035; EN IEC 61000-3-2; EN 61000-3-3
-
CompatibilityTeltonika TRB245, TRB246, TRB255, TRB256, TSW010, TSW114, TSW210, TSW304
-
Typical ApplicationsIndustrial IoT devices, routers, switches, DIN-rail installations
-
PackagingSmall retail box (estimated dimensions 10 × 4 × 7 cm), protective inner padding
