Sonoff MINI Duo Smart Switch Dimmer 2-Channel Wi‑Fi & Bluetooth 16A (with Neutral) - MINI-2GS

Description

Technical Specifications

• Product Name
  Sonoff MINI Duo Smart Switch Dimmer (MINI-2GS)
• Brand
  Sonoff
• Model / MPN
  MINI-2GS
• Category
  Smart Switch / Dimmer
• Channels
  2 independent channels (2 outputs)
• Max Current
  16 A (total)
• Recommended Max Per Channel
  Up to 10 A per channel for certain load types (see manufacturer guidelines)
• Connectivity
  Wi‑Fi, Bluetooth
• Smart Platforms
  Google Home, Amazon Alexa, Apple HomeKit, SmartThings, Matter, IFTTT
• Mobile App
  eWeLink (control, timers, scenes)
• Dimmer
  Yes (supports dimmable LED drivers/lights)
• Dry Contact
  No
• Neutral Required
  Yes (needs neutral connection)
• Power Measurement
  No (no built-in energy metering)
• Control Methods
  eWeLink app, voice control (via supported platforms), Bluetooth local control
• Installation
  Flush in-wall installation behind existing switch / fits inside standard switch box
• Dimensions (WxLxH)
  45 x 39.4 x 16.8 mm
• Material
  Plastic enclosure (typical fire-retardant ABS housing)
• Quantity in Package
  1 piece
• Maximum Channels
  2
• Compatible Use
  Control of lighting and other AC loads (observe recommended loads for LED/inductive devices)
• Mounting Location
  Inside electrical box / behind wall switch
• Included Accessories
  (not specified) module only (1 unit)

Ratings
