KVM Switch StarTech C2-DD46-UA2-CBL-KVM

Technical Specifications

• Number of computers controlled
  2
• Keyboard port type
  USB
• Mouse port type
  USB
• Video port type
  DisplayPort
• DisplayPorts quantity
  4
• DisplayPort version
  1.2
• Console ports
  3.5mm headphone, 3.5mm mic, DisplayPort, USB A
• Console USB ports quantity
  2
• Console DisplayPorts ports quantity
  2
• USB version
  2
• Audio connections
  Yes
• Headphone outputs
  2
• Number of microphone inputs
  2
• HD type
  4K Ultra HD
• Maximum resolution
  4096 x 2160 pixels
• Video bandwidth
  60 Hz
• Data transfer rate (max)
  0.48 Gbit/s
• Scan interval
  10,20,30,40,50,60 s
• Chipset
  SN8P2202SG
• Audio channels
  2
• Rack mounting
  No
• Product colour
  Black
• Housing material
  Acrylonitrile butadiene styrene (ABS)
• Cable length
  1.5 m
• LED indicators
  Yes
• Push button
  Yes
• Hot keys
  Yes
• Mean time between failures (MTBF)
  419293 h
• Built-in display
  No
• Power source
  USB
• Windows operating systems supported
  Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 IoT Enterprise, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 11, Windows 11 Enterprise, Windows 11 Enterprise x64, Windows 11 Home, Windows 11 Pro, Windows 11 x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 7 x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64
• Mac operating systems supported
  Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.15.3 Catalina, Mac OS X 11.0 Big Sur, Mac OS X 12.0 Monterey
• Other operating systems supported
  ChromeOS
• Sustainability compliance
  Yes
• Sustainability certificates
  RoHS
• Operating temperature (T-T)
  0 - 40 °C
• Storage temperature (T-T)
  -20 - 60 °C
• Operating relative humidity (H-H)
  0 - 90%
• Width
  90 mm
• Depth
  125 mm
• Height
  25 mm
• Weight
  600 g
• Package width
  160 mm
• Package depth
  100 mm
• Package height
  210 mm
• Package weight
  700 g
• Quick installation guide
  Yes
• Master (outer) case width
  440 mm
• Master (outer) case length
  320 mm
• Master (outer) case height
  345 mm
• Products per master (outer) case
  12 pc(s)
• Display resolution at frequency
  4096x2160 @60Hz 3840x2160 @60Hz 5120x1440 @60Hz 3440x1440 @60Hz 2560x1440 @60Hz 2560x1080 @60Hz 1920x1200 @60Hz 1920x1080 @60Hz
