Network Switch QNAP SWI QSW-M408-2C

Technical Specifications

• Number of basic switching RJ-45 Ethernet ports
  2
• Basic switching RJ-45 Ethernet ports type
  10G Ethernet (100/1000/10000)
• Number of Gigabit Ethernet (copper) connections
  8th
• Number of combo SPF ports
  2
• Console port
  RJ-45
• VLAN support
  yes
• Virtual LAN functions
  Port-based VLAN, private VLAN
• Network standard
  IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1w, IEEE 802.3, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3an, IEEE 802.3az, IEEE 802.3bz, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
• 10G support
  yes
• Copper ethernet cabling technology
  10BASE-T, 10GBASE-T, 1000BASE-LX, 1000BASE-SX, 1000BASE-T
• supported cable types
  Cat5, Cat5e, Cat6
• Full duplex
  yes
• Spanning Tree Protocol
  yes
• Support data flow control
  yes
• Auto-negotiation function
  yes
• MAC address table
  16,000 entries
• Routing / switching capacity
  96 Gbit / s
• Jumbo frames support
  yes
• Jumbo frames
  9000
• DHCP functions
  DHCP client
• Access Control List
  yes
• IGMP snooping
  yes
• Certification
  CE, FCC, VCCI, BSMI
• Rack installation
  no
• Stackable
  no
• Product color
  White
• Reset button
  yes
• LED indicators
  Activity, link, performance, speed, status
• Number of fans
  1 fan
• Switch type
  Managed
• Switch level
  L2
• Quality of Service (QoS) support
  yes
• Web based management
  yes
• Noise level
  21 dB
• Package weight
  1.57 kg
• Supplied cables
  AC
• Quick start overview
  yes
• width
  290 mm
• depth
  127 mm
• height
  42.5 mm
• Weight
  1.15 kg
• Operating temperature range
  0 - 45 ° C
• Humidity in operation
  5 - 95%
• Power over Ethernet (PoE)
  no
• Power supply included
  yes
• AC input voltage
  100-240V
• AC input frequency
  50/60 Hz
• Power consumption (max.)
  22.04 W
