Network Switch Intellinet 28-P PoE+ Managed 4x10GbE 450W

Technical Specifications

• MAC address table
  16k
• Buffer memory
  12 Mbits
• Forwarding rate
  95.23 Mpps
• MTBF
  90k hours
• Backplane speed/switch fabric
  128 Gbps
• Switch architecture
  store and forward
• Configuration options
• Port link speed
  10 Mbps, 100 Mbps, 1000 Mbps or auto-negotiation
• Switch architecture
  store and forward
• Port Aggregation/LACP
  16 groups
• Access management filtering
  SNMP, HTTP, HTTPS, SSH, TELNET Quality of Service (QoS)
• DHCP
  Client/Option82/Snooping
• Certifications
  FCC, CE, RoHS, UKCA, NDAA
• Pin 1
  DC (+)
• Pin 2
  DC (+)
• Pin 3
  DC (-)
• Pin 6
  DC (-)
• Input
  100.0 - 240.0 VAC, 50 - 60 Hz, internal power supply
• Power output per port
  30.0 W
• PoE power budget
  370.0 watts (max.)
• Power consumption
  425.0 W (max.)
• Dimensions (L x W x H)
  208 x 440 x 44 mm (8.19 x 17.32 x 1.73 in.)
• Net weight
  3 kg (6.61 lbs.)
• Gross weight
  3.85 kg (8.49 lbs.)
• Operating temperature
  0 - 45°C (32 - 113°F)
• Storage temperature
  -40 - 70°C (-40 - 158°F)
• Operating humidity
  10 - 90% RH, non-condensing
• Storage humidity
  5 - 90% RH, non-condensing
