Network Switch Intellinet 24x GE Web-Managed Rackmount 2x SFP

Technical Specifications

• Number of basic switching RJ-45 Ethernet ports
  24
• Basic switching RJ-45 Ethernet ports type
  Gigabit Ethernet (10/100/1000)
• Number of installed SFP modules
  2
• VLAN support
  yes
• Network standard
  IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
• 10G support
  no
• supported cable types
  Cat3, Cat4, Cat5, Cat5e
• Port mirroring
  yes
• Full duplex
  yes
• Support data flow control
  yes
• Auto-negotiation function
  yes
• Rate restriction
  yes
• Link aggregation
  yes
• Spanning Tree Protocol
  yes
• Broadcast storm control
  yes
• MAC address table
  8000 entries
• Routing / switching capacity
  52 Gbit / s
• Transfer rate
  1.488 Mpps
• Store-and-forward
  yes
• Jumbo frames support
  yes
• Jumbo frames
  9216
• Access Control List
  yes
• IGMP snooping
  yes
• Authentication
  Port based authentication
• Multicast support
  yes
• Number of filtered multicast groups
  8th
• Certification
  FCC Class A, CE
• Rack installation
  yes
• Form factor
  1U
• Product color
  black
• Housing material
  metal
• LED indicators
  yes
• System event log
  yes
• Switch type
  Managed
• Quality of Service (QoS) support
  yes
• Web based management
  yes
• Buffer size
  512 KB
• Supplied cables
  AC
• Rack mounting kit
  yes
• operating manual
  yes
• Mounting blocks included
  yes
• width
  440 mm
• depth
  205 mm
• height
  44 mm
• Weight
  2.2 kg
• Operating temperature range
  0 - 40 ° C
• Storage temperature range
  -40 - 70 ° C
• Humidity in operation
  10 - 90%
• AC input voltage
  100-240V
• AC input frequency
  50-60 Hz
• Power consumption (max.)
  20 W
