Network Switch DIGITUS Industry Gigabit Flat , 5-Port

Technical Specifications

• Number of basic switching RJ-45 Ethernet ports
  5
• Basic switching RJ-45 Ethernet ports type
  Gigabit Ethernet (10/100/1000)
• Network standard
  IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x
• 10G support
  yes
• Copper ethernet cabling technology
  1000BASE-TX
• Half duplex
  yes
• Full duplex
  no
• Ethernet LAN data transfer rates
  10,100,1000 Mbit / s
• Auto-aging of MAC addresses supported
  yes
• Link aggregation
  yes
• Self-learning of MAC addresses supported
  yes
• Auto MDI / MDI-X
  yes
• Active link detection
  yes
• MAC address table
  2 entries
• Routing / switching capacity
  10 Gbit / s
• Rack installation
  yes
• Stackable
  no
• Product color
  black
• Housing material
  metal
• LED indicators
  Link, performance
• Wall mounting
  yes
• International protection class (IP code)
  IP40
• Switch type
  Managed
• width
  90 mm
• depth
  121 mm
• height
  37 mm
• Operating temperature range
  -40 - 85 ° C
• Storage temperature range
  -40 - 85 ° C
• Humidity in operation
  5 - 95%
• Storage humidity
  5 - 95%
• Power over Ethernet (PoE)
  no
• Power supply included
  yes
• DC input voltage
  12 - 48 V.
• Power consumption (max.)
  5 W
