Motherboard Biostar A520MT

Technical Specifications

• Processor manufacturer
  AMD
• Compatible processor series
  AMD Ryzen 3
• Audio output channels
  7.1 channels
• Motherboard form factor
  micro ATX
• Motherboard chipset
  AMD A520
• Audio chip
  Realtek ALC897
• Motherboard chipset family
  AMD
• Supported memory types
  DDR4-SDRAM
• Memory slots type
  DIMM
• Number of memory slots
  2
• Supported memory clock speeds
  3200
• Maximum internal memory
  64 GB
• Depth
  208 mm
• Width
  235 mm
• Ethernet LAN
  Y
• Wi-Fi
  N
• LAN controller
  Realtek RTL8111H
• Number of COM connectors
  1
• CPU fan connector
  Y
• TPM connector
  Y
• USB 3.2 Gen 1 (3.1 Gen 1) connectors
  1
• USB 2.0 connectors
  2
• Number of SATA III connectors
  4
• Front panel audio connector
  Y
• ATX Power connector (24-pin)
  Y
• RAID levels
  1
• Supported storage drive interfaces
  M.2, SATA III
• RAID support
  Y
• HDMI ports quantity
  1
• Headphone outputs
  1
• Microphone in
  Y
• Line-in
  Y
• USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
  4
• DisplayPorts quantity
  1
• USB 2.0 ports quantity
  2
• Ethernet LAN (RJ-45) ports
  1
