Access Point TP-Link AX1800 Wall Plate WiFi 6 v1

Technical Specifications

• Band steering
  Y
• Automatic channel selection
  Y
• Airtime Fairness (ATF)
  Y
• Automatic channel scanning
  Y
• Transmitting power (FCC)
  21 dBm
• Ethernet LAN data rates
  1000 Mbit/s
• Maximum data transfer rate (5 GHz)
  1201 Mbit/s
• Cabling technology
  10/100/1000Base-T(X)
• Transmitting power (CE)
  20 dBm
• Networking standards
  IEEE 802.11ac
• Maximum data transfer rate
  1774 Mbit/s
• 2.4 GHz
  Y
• 5 GHz
  Y
• MIMO
  Y
• Quality of Service (QoS) support
  Y
• Maximum data transfer rate (2.4 GHz)
  574 Mbit/s
• Rate limiting
  Y
• MIMO type
  Multi User MIMO
• VLAN support
  Y
• LED indicators
  Power
• Reset button
  Y
• Placement
  Wall
• Product colour
  White
• On/off switch
  Y
• Power over Ethernet (PoE)
  Y
• Service Set Identifier (SSID) features
  Multiple SSIDs
• Remote Authentication Dial-In User Service (RADIUS)
  Y
• Security algorithms
  WPA
• Number of SSID supported
  16
• Access Control List (ACL)
  Y
• Operating relative humidity (H-H)
  10 - 90%
• Operating temperature (T-T)
  0 - 40 °C
• Storage temperature (T-T)
  -40 - 70 °C
• Storage relative humidity (H-H)
  5 - 90%
• Syslog
  Y
• Height
  20 mm
• Depth
  86 mm
• Width
  143 mm
• STelnet using SSH v2
  Y
• Ethernet LAN (RJ-45) ports
  4
• Antenna type
  Internal
