The BNC59F is a male BNC crimp plug for RG59 coaxial cable with a gold-plated center pin, designed for reliable 75 Ohm signal connections. It is compatible with RG59 and RG62 cable from rolls, and is not intended for premade siamese cable assemblies. The connector uses a bayonet locking mechanism...
More
Network Cables BNC crimp plug for RG59 cable with gold pin BNC59F
Product Code: 1200652713
Out of stock
3,49 €
Quantity:
Add
Need Help? Fill in your details so we can call you immediately!
TBI Bank
Buy Now Pay Later.
4 installments 0% επιτόκιο, 20€ έως 300€
3 to 60 installments 300€ έως 100.00€
- 1. Ship with ACS Courier
- 2. Αποστολές με μεταφορικές εταιρίες για ογκώδη αντικείμενα
-
3. Pickup from BoxNow automated machine:
Με την BoxNow μπορείς να παραλάβεις το δέμα σου από Αυτόματο Μηχάνημα Παραλαβής που βρίσκεται κοντά σου, όλες τις ώρες της ημέρας 24/7. Η υπηρεσία έχει χρέωση 3€. Υπάρχει δυνατότητα αντικαταβολής με επιπλέον χρέωση 1€.
-
4. Pickup from the store:
Leof. El. Venizelou 73 (former Theseos), Kallithea
Συμπληρώστε τον ταχυδρομικό κωδικό για να λάβετε εκτίμηση τρόπου και κόστους μεταφορικών.
The BNC59F is a male BNC crimp plug for RG59 coaxial cable with a gold-plated center pin, designed for reliable 75 Ohm signal connections. It is compatible with RG59 and RG62 cable from rolls, and is not intended for premade siamese cable assemblies. The connector uses a bayonet locking mechanism for quick, secure mating and is installed by stripping the cable, attaching the pin to the center conductor, then crimping the ferrule. It is well suited for CCTV, security, and RF applications.
-
Connector TypeBNC male crimp plug
-
Product TypeCoaxial cable connector
-
Cable CompatibilityRG59, RG62
-
Impedance75 Ohm
-
Center ContactGold-plated pin
-
Body PlatingNickel-plated body
-
Design2-piece or 3-piece crimp connector
-
Coupling MechanismBayonet lock
-
Frequency RangeDC to 4 GHz vibrating, up to 11 GHz static
-
Center Conductor Size20-22 AWG
-
Ferrule Crimp SizeApproximately 0.255 inch
-
Pin Crimp SizeApproximately 0.068 inch
-
ApplicationCCTV, security cameras, RF installations
-
InstallationStrip cable, attach pin, insert body, crimp ferrule
-
ModelBNC59F
-
EAN5711045233166
-
MPNBNC59F
Ratings
Description
The BNC59F is a male BNC crimp plug for RG59 coaxial cable with a gold-plated center pin, designed for reliable 75 Ohm signal connections. It is compatible with RG59 and RG62 cable from rolls, and is not intended for premade siamese cable assemblies. The connector uses a bayonet locking mechanism for quick, secure mating and is installed by stripping the cable, attaching the pin to the center conductor, then crimping the ferrule. It is well suited for CCTV, security, and RF applications.
Technical Specifications
-
Connector TypeBNC male crimp plug
-
Product TypeCoaxial cable connector
-
Cable CompatibilityRG59, RG62
-
Impedance75 Ohm
-
Center ContactGold-plated pin
-
Body PlatingNickel-plated body
-
Design2-piece or 3-piece crimp connector
-
Coupling MechanismBayonet lock
-
Frequency RangeDC to 4 GHz vibrating, up to 11 GHz static
-
Center Conductor Size20-22 AWG
-
Ferrule Crimp SizeApproximately 0.255 inch
-
Pin Crimp SizeApproximately 0.068 inch
-
ApplicationCCTV, security cameras, RF installations
-
InstallationStrip cable, attach pin, insert body, crimp ferrule
-
ModelBNC59F
-
EAN5711045233166
-
MPNBNC59F
