Motherboard Gigabyte Z790 EAGLE AX (Z790,S1700,ATX,DDR5)

Technical Specifications

• BIOS type
  UEFI AMI
• BIOS memory size
  256 Mbit
• ACPI version
  5.0
• Clear CMOS jumper
  Clear CMOS button
• System management BIOS (SMBIOS) version
  2.7
• Desktop Management Interface (DMI) version
  2.7
• processor manufacturer
  Intel
• processor socket
  LGA 1700
• Compatible processors
  Intel Celeron, Intel Core™ i3, Intel Core™ i5, Intel Core™ i7, Intel Core™ i9, Intel Pentium Gold
• Maximum number of SMP processors
  1
• Supported processor slots
  LGA 1700
• Maximum internal memory supported by the processor
  192GB
• Supported memory
  DDR5 SDRAM
• Number of memory slots
  4
• RAM type
  DIMM
• Memory channels
  Two-channel
• Number of USB 2.0 interfaces
  2
• USB 3.2 Gen 1 (3.1 Gen 1) ports
  1
• USB 3.2 Gen 2 (3.1 Gen 2) ports
  1
• SATA III connectors
  4
• Total number of SATA ports
  4
• Number of USB 2.0 ports
  2
• USB 3.2 Gen 1 (3.1 Gen 1) Number of Type A ports
  4
• USB 3.2 Gen 2 (3.1 Gen 2) Number of Type A ports
  1
• USB 3.2 Gen 2x2 Type-C Number of ports
  1
• Number of Ethernet LAN ports (RJ-45)
  1
• Number of PS/2 connections
  1
• Number of HDMI ports
  1
• HDMI version
  2.1
• Number of DisplayPort connections
  1
• DisplayPorts version
  1.2
• Headphone outputs
  1
• Component for
  PC
• Motherboard form factor
  ATX
• Motherboard chipset family
  Intel
• Motherboard chipset
  Intel Z790 Express
• Audio chip
  Realtek ALC897
• Audio channels
  7.1 channels
• Product color
  Brown
• PC health monitoring
  Fan, temperature, voltage, water cooling
• Energy source
  ATX
• Supports Windows operating systems
  Windows 10 x64, Windows 11 x64
• PCI Express x1 (Gen 3.x) connectors
  2
• PCI Express x16 slots (Gen 4.x)
  1
• PCI Express x16 (Gen 3.x) connectors
  1
• PCI Express x16 slots (Gen 5.x)
  1
• Number of M.2 (M) slots
  3
• Packaging width
  335mm
• Packaging depth
  270mm
• Packaging height
  80mm
• Package weight
  1.81kg
• Battery weight
  3g
• Lithium weight per battery
  0.07g
• Number of battery cells
  1
• Rechargeable battery/battery technology
  Lithium Manganese Dioxide (LiMnO2)
• Rechargeable battery/battery type
  CR2032
• Quantity per shipping box
  1 piece(s)
• Country of origin
  China
• Cables included
  SATA
