Modem Allnet ISP Bridge VDSL2 with Vectoring/Point-to-Point Slave & 2x PoE IEEE802.3at Ports ALL-MC116SPV-VDSL2
εως 36 δόσεις με πιστωτική κάρτα
Need Help? Fill in your details so we can call you immediately!
4 installments 0% επιτόκιο, 20€ έως 300€
3 to 60 installments 300€ έως 100.00€
σε όλη την Ελλάδα
Related Products
Router TP-Link EX520 WLAN Gigabit Ethernet Dual-Band (2,4 GHz/5 GHz) Black
Router Cudy WR1300 wireless Gigabit Ethernet Dual-band (2.4 GHz / 5 GHz) White
Router Mercusys MR25BE wireless Gigabit Ethernet Dual-band (2.4 GHz / 5 GHz) Black
Router ZTE G5C - Gigabit Ethernet dual-band (2.4 GHz / 5 GHz) Wi-Fi 6 4G/5G wireless in White
Router ZTE MF986D 4G UFI LTE CAT12/13 1x USB Type C, 1x SIM socket 2x TS-9
Router Cudy M11000(1-Pack) BE11000 2.5G Tri-Band Wi-Fi 7 Mesh Solution
The ALL-MC116SPV-VDSL2 is a cost-effective, unmanaged VDSL2 bridge modem designed specifically for telecommunications and ISP applications. Its vectoring technology supports enhanced data transmission efficiency by reducing interference among lines, resulting in improved network performance.
Equipped with Ethernet Ports, this modem has 2x 10/100/1000Base-T ports, each with Power over Ethernet (PoE) capabilities. This feature allows devices such as WLAN access points and tablets to operate directly from the modem, supporting a maximum power output of 30W per port.
The physical interfaces include a combo RJ-11/Terminal block for the line and an additional RJ-11 port for POTS/ISDN devices. There is also a reset button for easy configuration recovery.
Powering the device is simple with a DC 54V power supply, fully compliant with IEC/EN/UL60601-1 standards and providing up to 60W total output.
LED indicators provide real-time status updates for Act/Link, PoE, and overload, ensuring users can swiftly diagnose potential issues.
With dimensions of 137 x 100 x 27 mm and a weight of approximately 0.42 kg, the modem is compact and lightweight. Its operational temperature range of 0°C to 50°C, along with a storage range of -20°C to 70°C and 10% to 90% humidity, ensures it can perform reliably in various environments.
Finally, the ALL-MC116SPV-VDSL2 meets strict standards compliance, including IEEE 802.3ab, ensuring compatibility across various network configurations.
-
StandardsIEEE 802.3ab, IEEE802.3u, IEEE 802.3z, ITU-T G993.2 VDSL2
-
Ethernet Ports2x 10/100/1000Base-T
-
PoE CapabilityIEEE802.3at
-
Line Port1x RJ-11/Terminal block combo
-
POTS/ISDN Port1x RJ-11
-
Power SupplyDC 54V AC to DC medial compliant IEC/EN/UL60601-1 1x MOPP
-
Maximum Power Output60W
-
LED IndicatorsAct/Link, PoE, Overload for Ethernet ports; Act/Link, Line Mode for VDSL2
-
Dimensions137 x 100 x 27 mm
-
Weight0.42 kg
-
Operating Temperature0°C to 50°C
-
Storage Temperature-20°C to 70°C
-
Humidity10% to 90% non-condensing
-
ComplianceCE, FCC, RoHS
Ratings
Description
The ALL-MC116SPV-VDSL2 is a cost-effective, unmanaged VDSL2 bridge modem designed specifically for telecommunications and ISP applications. Its vectoring technology supports enhanced data transmission efficiency by reducing interference among lines, resulting in improved network performance.
Equipped with Ethernet Ports, this modem has 2x 10/100/1000Base-T ports, each with Power over Ethernet (PoE) capabilities. This feature allows devices such as WLAN access points and tablets to operate directly from the modem, supporting a maximum power output of 30W per port.
The physical interfaces include a combo RJ-11/Terminal block for the line and an additional RJ-11 port for POTS/ISDN devices. There is also a reset button for easy configuration recovery.
Powering the device is simple with a DC 54V power supply, fully compliant with IEC/EN/UL60601-1 standards and providing up to 60W total output.
LED indicators provide real-time status updates for Act/Link, PoE, and overload, ensuring users can swiftly diagnose potential issues.
With dimensions of 137 x 100 x 27 mm and a weight of approximately 0.42 kg, the modem is compact and lightweight. Its operational temperature range of 0°C to 50°C, along with a storage range of -20°C to 70°C and 10% to 90% humidity, ensures it can perform reliably in various environments.
Finally, the ALL-MC116SPV-VDSL2 meets strict standards compliance, including IEEE 802.3ab, ensuring compatibility across various network configurations.
Technical Specifications
-
StandardsIEEE 802.3ab, IEEE802.3u, IEEE 802.3z, ITU-T G993.2 VDSL2
-
Ethernet Ports2x 10/100/1000Base-T
-
PoE CapabilityIEEE802.3at
-
Line Port1x RJ-11/Terminal block combo
-
POTS/ISDN Port1x RJ-11
-
Power SupplyDC 54V AC to DC medial compliant IEC/EN/UL60601-1 1x MOPP
-
Maximum Power Output60W
-
LED IndicatorsAct/Link, PoE, Overload for Ethernet ports; Act/Link, Line Mode for VDSL2
-
Dimensions137 x 100 x 27 mm
-
Weight0.42 kg
-
Operating Temperature0°C to 50°C
-
Storage Temperature-20°C to 70°C
-
Humidity10% to 90% non-condensing
-
ComplianceCE, FCC, RoHS
