The Legrand KEOR DK Online (VFI) double-conversion UPS, model 311348 (SKU: 266-60-LEGDAKER5N, EAN: 3414972944809), provides 5000 VA / 5000 W continuous output with a unity power factor (PF=1). It features a clear LCD display, PWM control, hot?swappable maintenance?free VRLA batteries (12V/9Ah), and...
More
Legrand KEOR DK Online UPS 5000VA / 5000W with LCD Model 311348
Product Code: 1161742289
Upon Order
3.029,94 €
or
94,62€ / month
εως 36 δόσεις με πιστωτική κάρτα
With the purchase of this product you earn 9090 Bytes
Quantity:
Add
Need Help? Fill in your details so we can call you immediately!
Έως 36 Δόσεις. Δείτε το πλάνο δόσεων:
TBI Bank
Buy Now Pay Later.
4 installments 0% επιτόκιο, 20€ έως 300€
3 to 60 installments 300€ έως 100.00€
- 1. Ship with ACS Courier
- 2. Αποστολές με μεταφορικές εταιρίες για ογκώδη αντικείμενα
-
3. Pickup from BoxNow automated machine:
Με την BoxNow μπορείς να παραλάβεις το δέμα σου από Αυτόματο Μηχάνημα Παραλαβής που βρίσκεται κοντά σου, όλες τις ώρες της ημέρας 24/7. Η υπηρεσία έχει χρέωση 3€. Υπάρχει δυνατότητα αντικαταβολής με επιπλέον χρέωση 1€.
-
4. Pickup from the store:
Leof. El. Venizelou 73 (former Theseos), Kallithea
Συμπληρώστε τον ταχυδρομικό κωδικό για να λάβετε εκτίμηση τρόπου και κόστους μεταφορικών.
The Legrand KEOR DK Online (VFI) double-conversion UPS, model 311348 (SKU: 266-60-LEGDAKER5N, EAN: 3414972944809), provides 5000 VA / 5000 W continuous output with a unity power factor (PF=1). It features a clear LCD display, PWM control, hot?swappable maintenance?free VRLA batteries (12V/9Ah), and can be used as tower or rack (rack mounting optional). Input range: 176280 V, input frequency: 4565 Hz. Output: 200240 V, output frequency: 5060 Hz, sine wave output with ?2% THD (linear load). Overall efficiency ?95.1% (up to 99% in ECO mode). Communication: USB and RS?232 (SNMP not included). Outputs: IEC type outlets 8 x C13, 2 x C19, plus 1 fixed connection. Other specs: sound level 45 dB, IP20, operating temperature 040 °C, storage -1050 °C, dimensions 176 x 440 x 700 mm, weight 54 kg. Contains rechargeable VRLA batteries (20 single elements). Ideal for network equipment, servers, workstations and other critical IT loads requiring continuous, clean power.
-
BrandLEGRAND
-
ModelKEOR DK (311348)
-
TypeOn-Line / Double Conversion (VFI)
-
Apparent power (VA)5000 VA
-
Output power (W)5000 W
-
Output power factor1 (unity)
-
Overall efficiency95.1%
-
Efficiency (ECO mode)99%
-
Input voltage range176 - 280 V
-
Input frequency range45 - 65 Hz
-
Output voltage range200 - 240 V
-
Output frequency range50 - 60 Hz
-
Waveform outputSine Wave
-
Max. voltage distortion output (linear load)2%
-
UPS technologyOnline (VFI)
-
Number of input phases1
-
Number of output phases1
-
Output connections (C13)8
-
Output connections (C19)2
-
Fixed output connection1
-
Communication interfacesUSB, RS-232
-
SNMPNo
-
Potential free switch contactNo
-
Auto shut down functionNo
-
Hot-swappable batteriesYes (Plug & Play)
-
Battery typeMaintenance-free Lead-acid, VRLA 12V/9Ah
-
Number of battery elements (pack)20
-
Contains batteriesYes
-
Power consumption (idle)101 W
-
Noise level45 dB
-
IP ratingIP20
-
Dimensions (H x W x D)176 x 440 x 700 mm
-
Weight54 kg
-
Operating temperature0 - 40 °C
-
Storage temperature-10 - 50 °C
-
Mounting optionsTower (standard) and rack (optional)
-
Regulation typeI : Industrial (not Portable)
-
Package location of batteriesProduct includes a battery
Ratings
Description
The Legrand KEOR DK Online (VFI) double-conversion UPS, model 311348 (SKU: 266-60-LEGDAKER5N, EAN: 3414972944809), provides 5000 VA / 5000 W continuous output with a unity power factor (PF=1). It features a clear LCD display, PWM control, hot?swappable maintenance?free VRLA batteries (12V/9Ah), and can be used as tower or rack (rack mounting optional). Input range: 176280 V, input frequency: 4565 Hz. Output: 200240 V, output frequency: 5060 Hz, sine wave output with ?2% THD (linear load). Overall efficiency ?95.1% (up to 99% in ECO mode). Communication: USB and RS?232 (SNMP not included). Outputs: IEC type outlets 8 x C13, 2 x C19, plus 1 fixed connection. Other specs: sound level 45 dB, IP20, operating temperature 040 °C, storage -1050 °C, dimensions 176 x 440 x 700 mm, weight 54 kg. Contains rechargeable VRLA batteries (20 single elements). Ideal for network equipment, servers, workstations and other critical IT loads requiring continuous, clean power.
Technical Specifications
-
BrandLEGRAND
-
ModelKEOR DK (311348)
-
TypeOn-Line / Double Conversion (VFI)
-
Apparent power (VA)5000 VA
-
Output power (W)5000 W
-
Output power factor1 (unity)
-
Overall efficiency95.1%
-
Efficiency (ECO mode)99%
-
Input voltage range176 - 280 V
-
Input frequency range45 - 65 Hz
-
Output voltage range200 - 240 V
-
Output frequency range50 - 60 Hz
-
Waveform outputSine Wave
-
Max. voltage distortion output (linear load)2%
-
UPS technologyOnline (VFI)
-
Number of input phases1
-
Number of output phases1
-
Output connections (C13)8
-
Output connections (C19)2
-
Fixed output connection1
-
Communication interfacesUSB, RS-232
-
SNMPNo
-
Potential free switch contactNo
-
Auto shut down functionNo
-
Hot-swappable batteriesYes (Plug & Play)
-
Battery typeMaintenance-free Lead-acid, VRLA 12V/9Ah
-
Number of battery elements (pack)20
-
Contains batteriesYes
-
Power consumption (idle)101 W
-
Noise level45 dB
-
IP ratingIP20
-
Dimensions (H x W x D)176 x 440 x 700 mm
-
Weight54 kg
-
Operating temperature0 - 40 °C
-
Storage temperature-10 - 50 °C
-
Mounting optionsTower (standard) and rack (optional)
-
Regulation typeI : Industrial (not Portable)
-
Package location of batteriesProduct includes a battery
