Sku: 1173522465
Κεραία Δικτύου Poynting 5G/LTE Mast/Wand/Window A-XPOL-0001-V2-41 White SMA (M) 4dbi 4x4 MIMO Omnidirectional
202,22 €
Up to 36 instalments by credit card x 6,32€ / month
| Installment plan | Amount / month |
|---|---|
| 2 | 104,00 € |
| 4 | 52,28 € |
| 6 | 35,04 € |
| 8 | 26,42 € |
| 10 | 21,25 € |
| 12 | 17,80 € |
| 18 | 12,05 € |
| 24 | 9,18 € |
| 36 | 6,32 € |
Product Availability
για καλύτερη τιμή!
Need help?
Συμπλήρωσε τα στοιχεία σου για να σε καλέσουμε άμεσα.
Call us now!
Methods of Pickup/Shipment
-
Pickup from the store:El. Ave. Venizelou 73 (formerly Theseos), Kallithea
-
Pick up from a BoxNow machine:With BoxNow you can pick up your parcel from an Automatic Pickup Machine that is near you at all hours of the day 24/7. Possibility of cash on delivery with an additional fee of €1
-
Shipping to your location (Calculate shipping):
Share this:
Detailed Description
The Poynting Antennas 5G/LTE Mast/Wand/Fenster A-XPOL-0001-V2-41 is an advanced, cross-polarized, omnidirectional antenna tailored for 5G, 4G, and LTE networks.
With a robust design and an IP65 rating, this antenna is engineered for harsh environments. It guarantees durability under extreme temperatures and high humidity. There are two configurations available: 2x2 MIMO and 4x4 MIMO, catering to various signal enhancement needs.
Technical Highlights:
- **Wide Frequency Band**: Covers 617 960 MHz, 1427 1517 MHz, 1710 2700 MHz, and 3400 3800 MHz.
- **Outstanding Gain**: Peak gain of 4 dBi ensures superior performance.
- **Cross-Polarization**: Enhances signal capture and transmission in diverse environments.
- **Flexible MIMO Options**: Choose between 2x2 and 4x4 MIMO setups for optimal performance.
**Environmental Specifications:**
- Operating Temperature: -40°C to +70°C
- Humidity Tolerance: Up to 98% relative humidity
- Wind Resistance: Up to 250 km/h without window mount
In conclusion, the A-XPOL-0001-V2-41 is an essential component for anyone requiring reliable, high-performance connectivity.
Specifications
-
Frequency Bands
- 617 960 MHz, 1427 1517 MHz, 1710 2700 MHz, 3400 3800 MHz
-
Peak Gain
- 4 dBi
-
Polarization
- Cross-polarized
-
MIMO Configuration
- 2x2 and 4x4 MIMO
-
Coax Cable Length
- 5 meters
-
Coax Cable Loss
- 0.385 dB/m at 900 MHz, 0.507 dB/m at 1500 MHz, 0.565 dB/m at 1800 MHz, 0.666 dB/m at 2400 MHz, 0.788 dB/m at 3000 MHz
-
Operating Temperature Range
- -40°C to +70°C
-
Operating Humidity
- up to 98% relative humidity
-
Wind Survival
- up to 250 km/h
-
Flammability Rating
- UL 94-HB
-
Impact Resistance
- IK 10
-
Product Dimensions
- 247 mm x 157 mm x 88 mm
-
Packaged Dimensions
- 270 mm x 190 mm x 100 mm
-
Product Weight
- 1.240 kg
-
Packaged Weight
- 1.340 kg
