Καλώδιο Οπτικής Ίνας Equip LC/APC->LC/APC 5.00m Single Simp.OS2 Yellow
για καλύτερη τιμή!
Συμπλήρωσε τα στοιχεία σου για να σε καλέσουμε άμεσα.
-
Pickup from the store:El. Ave. Venizelou 73 (formerly Theseos), Kallithea
-
Pick up from a BoxNow machine:With BoxNow you can pick up your parcel from an Automatic Pickup Machine that is near you at all hours of the day 24/7. Possibility of cash on delivery with an additional fee of €1
-
Shipping to your location (Calculate shipping):
Detailed Description
The **Equip LC/APC->LC/APC 5.00m Single Simp.OS2 Yellow** fiber optic patch cable is designed for optimal performance in a variety of applications, specifically tailored for long-distance transmissions. Here are key features:
Connectors: The cable features LC/APC to LC/APC connectors, known for their Angled Physical Contact design which minimizes back reflection.
Fiber Specifications: This cable utilizes singlemode fiber with the following specifications:
- Core Diameter: 9 µm
- Cladding Diameter: 125 µm
The fiber adheres to the G.657.A1 standard, providing a bend-insensitive solution ideal for challenging installations.
Color and Structure: Recognized by its yellow color, typical for singlemode cables, it features a simplex structure accommodating a single fiber.
Temperature Compatibility: The cable performs effectively within an operational temperature range of approximately -40°C to 85°C, making it suitable for various environments.
Packaging: Often packaged in individual polybags for protection, its dimensions are optimized for easy handling.
Specifications
-
Connectors
- LC/APC to LC/APC
-
Fiber Type
- Singlemode OS2
-
Fiber Core Diameter
- 9 µm
-
Cladding Diameter
- 125 µm
-
Cable Color
- Yellow
-
Cable Structure
- Simplex
-
Fiber Grade
- G.657.A1
-
Sheath Material
- LSZH
-
Sheath Diameter
- 3 mm
-
Temperature Range
- -40°C to 85°C
