Inverter Schwaiger NEP 800/600W

The Inverter Schwaiger NEP 800/600W is an exceptional microinverter crafted for balcony power plants and residential solar installations. This device efficiently converts direct current (DC) from photovoltaic (PV) panels into alternating current (AC) for household use or to feed into the power grid.

With a peak output power of 800W, and a continuous AC output around 750W/768W, it supports up to two solar panels, optimizing solar energy utilization. The inverter is designed with high efficiency ratings, around 95–95.5% CEC, ensuring minimal energy loss during conversion.

Key Technical Specifications:

• DC Input: Supports up to 1200W PV power
• Max DC Open Circuit Voltage: 60 Vdc
• Max DC Input Current: 17A per input (two inputs)
• MPPT Accuracy: >99.5%, tracking range from 22 to 55 Vdc
• AC Output: Rated Power: 750 W, Rated Current: 3.26 A, Nominal Voltage: 230 Vac, Frequency: 50 Hz, Power Factor: 0.8
• Inverter Topology: Isolated transformer with basic insulation
• Protection: Overcurrent, fault current, active anti-islanding
• Operating Temperature: -40°C to +85°C
• Enclosure Protection: NEMA-6 / IP66 / IP67 rated

This compact inverter, measuring 268 x 250 x 42 mm and weighing 2.9 kg, is designed for ease of handling and installation. Additional features include a free monitoring app for system management and compliance with various certifications, making it suitable for global installations.
