Hager Witty One Wall-mounted Three-phase Charging Station 7 kW Type 2 (XVR111S)
εως 36 δόσεις με πιστωτική κάρτα
Need Help? Fill in your details so we can call you immediately!
Έως 36 Δόσεις. Δείτε το πλάνο δόσεων:
TBI Bank
Buy Now Pay Later.
4 installments 0% επιτόκιο, 20€ έως 300€
3 to 60 installments 300€ έως 100.00€
- 1. Ship with ACS Courier
- 2. Αποστολές με μεταφορικές εταιρίες για ογκώδη αντικείμενα
-
3. Pickup from BoxNow automated machine:
Με την BoxNow μπορείς να παραλάβεις το δέμα σου από Αυτόματο Μηχάνημα Παραλαβής που βρίσκεται κοντά σου, όλες τις ώρες της ημέρας 24/7. Η υπηρεσία έχει χρέωση 3€. Υπάρχει δυνατότητα αντικαταβολής με επιπλέον χρέωση 1€.
-
4. Pickup from the store:
Leof. El. Venizelou 73 (former Theseos), Kallithea
Συμπληρώστε τον ταχυδρομικό κωδικό για να λάβετε εκτίμηση τρόπου και κόστους μεταφορικών.
-
Product NameHager Witty One Επιτοίχιος Τριφασικός Σταθμός Φόρτισης 7 kW Type 2 (XVR111S)
-
ManufacturerHager
-
Model / MPNXVR111S
-
SKULPEHAGSTL0002
-
EAN3250610103487
-
Mounting StyleWall mount (Επιτοίχιος)
-
Number of Phases3 (Τριφασικός)
-
Charging Power7 kW (listed) — connected load max: up to 11 kW
-
Rated Voltage400 V
-
Rated Current16 A
-
Connector TypeType 2 (Typ 2S)
-
Cable Length4.5 m
-
Cable ColourBlack
-
Housing MaterialPlastic
-
Housing ColourBlack
-
Nominal Frequency50 - 60 Hz
-
IP RatingIP55
-
IK RatingIK10
-
Operating Temperature Range-25 to +50 °C
-
RoHS ComplianceYes
-
Connected Load (max)0.1 - 11 kW
-
Width250 mm
-
Depth150 mm
-
Height370 mm
-
Weight6.11 kg
-
WarningsBefore use, make sure the device is correctly installed by a qualified electrician; Disconnect the unit from the power supply during maintenance or servicing; Do not use the unit in a damp or wet environment to avoid the risk of electric shock.
-
Hazard PictogramsSubstances under pressure; Corrosion
Ratings
Description
Technical Specifications
-
Product NameHager Witty One Επιτοίχιος Τριφασικός Σταθμός Φόρτισης 7 kW Type 2 (XVR111S)
-
ManufacturerHager
-
Model / MPNXVR111S
-
SKULPEHAGSTL0002
-
EAN3250610103487
-
Mounting StyleWall mount (Επιτοίχιος)
-
Number of Phases3 (Τριφασικός)
-
Charging Power7 kW (listed) — connected load max: up to 11 kW
-
Rated Voltage400 V
-
Rated Current16 A
-
Connector TypeType 2 (Typ 2S)
-
Cable Length4.5 m
-
Cable ColourBlack
-
Housing MaterialPlastic
-
Housing ColourBlack
-
Nominal Frequency50 - 60 Hz
-
IP RatingIP55
-
IK RatingIK10
-
Operating Temperature Range-25 to +50 °C
-
RoHS ComplianceYes
-
Connected Load (max)0.1 - 11 kW
-
Width250 mm
-
Depth150 mm
-
Height370 mm
-
Weight6.11 kg
-
WarningsBefore use, make sure the device is correctly installed by a qualified electrician; Disconnect the unit from the power supply during maintenance or servicing; Do not use the unit in a damp or wet environment to avoid the risk of electric shock.
-
Hazard PictogramsSubstances under pressure; Corrosion
