Hager ADC910D Residual Current Device (RCD) 1+N 2P 10A 30mA Type AC 230/240V Hager ADC910D Residual Current Device (RCD) 1+N 2P 10A 30mA Type AC 230/240V
Hager ADC910D Residual Current Device (RCD) 1+N 2P 10A 30mA Type AC 230/240V
Hager ADC910D Residual Current Device (RCD) 1+N 2P 10A 30mA Type AC 230/240V
Hager ADC910D residual current device (RCD) 1+N, 2-pole (2P) protection. Rated current: 10 A. Residual/trip current: 30 mA (AC). Tripping characteristic: B. Breaking capacity (Icn): 6 kA. Type of residual current trip: AC. Rated operating voltage Ue: 240 V AC. Rated insulation voltage Ui: 2000 V....
More

Hager ADC910D Residual Current Device (RCD) 1+N 2P 10A 30mA Type AC 230/240V

Product Code: 1127746662
Upon Order
64,84 €
or
2,02€ / month

εως 36 δόσεις με πιστωτική κάρτα

loyalty icon
With the purchase of this product you earn 195 Loyalty Points
Quantity:
Add
support icon

Need Help? Fill in your details so we can call you immediately!

Description
Hager ADC910D residual current device (RCD) 1+N, 2-pole (2P) protection. Rated current: 10 A. Residual/trip current: 30 mA (AC). Tripping characteristic: B. Breaking capacity (Icn): 6 kA. Type of residual current trip: AC. Rated operating voltage Ue: 240 V AC. Rated insulation voltage Ui: 2000 V. Rated impulse withstand voltage Uimp: 6000 V. Frequency: 50 Hz. Power consumption: 3.4 W. Mechanical life: 2000 operations. Electrical life: 2000 operations. Operating temperature range: -25 °C to 40 °C. Storage temperature range: -25 °C to 70 °C. Installed dimensions (H x W x D): 83 mm x 35 mm x 68 mm. Ingress protection: IP2X. Compliance: RoHS. Quantity: 1. Brand: Hager. Model / MPN: ADC910D. EAN: 3250611010791.
Technical Specifications
Ratings
