Goobay singlemode fiber optic patch cable (OS2) 10 m with SC/APC (8°) to SC/APC (8°) connectors. Designed for FTTH, FTTB, FTTx installations and connection to Optical Network Terminals (ONT). Fiber: OS2 9/125 µm (G.657.A2). Jacket: LSZH (Low Smoke Zero Halogen), yellow. Cable outer diameter: 3 mm....
More
Goobay 10m Singlemode OS2 Fiber Optic Patch Cable SC/APC to SC/APC Yellow LSZH
Product Code: 1172727802
Available in 4 - 6 days
7,57 €
With the purchase of this product you earn 23 Bytes
Quantity:
Add
Need Help? Fill in your details so we can call you immediately!
TBI Bank
Buy Now Pay Later.
4 installments 0% επιτόκιο, 20€ έως 300€
3 to 60 installments 300€ έως 100.00€
- 1. Ship with ACS Courier
- 2. Αποστολές με μεταφορικές εταιρίες για ογκώδη αντικείμενα
-
3. Pickup from BoxNow automated machine:
Με την BoxNow μπορείς να παραλάβεις το δέμα σου από Αυτόματο Μηχάνημα Παραλαβής που βρίσκεται κοντά σου, όλες τις ώρες της ημέρας 24/7. Η υπηρεσία έχει χρέωση 3€. Υπάρχει δυνατότητα αντικαταβολής με επιπλέον χρέωση 1€.
-
4. Pickup from the store:
Leof. El. Venizelou 73 (former Theseos), Kallithea
Συμπληρώστε τον ταχυδρομικό κωδικό για να λάβετε εκτίμηση τρόπου και κόστους μεταφορικών.
Goobay singlemode fiber optic patch cable (OS2) 10 m with SC/APC (8°) to SC/APC (8°) connectors. Designed for FTTH, FTTB, FTTx installations and connection to Optical Network Terminals (ONT). Fiber: OS2 9/125 µm (G.657.A2). Jacket: LSZH (Low Smoke Zero Halogen), yellow. Cable outer diameter: 3 mm. Simplex construction. Supports high-speed transmission up to 100 Gbit/s. Minimum bend radius >30 mm. Kink protection provided. Operating temperature range -40°C to +85°C. Meets IEC 60754-2, IEC 60332-1 and IEC 61034 flammability/smoke standards. Manufacturer MPN: 59642, EAN: 4040849596421.
-
BrandGoobay
-
Model / MPN59642
-
SKU11.001.0026
-
EAN4040849596421
-
Product TypeFiber optic patch cord (simplex)
-
Fiber TypeSinglemode OS2 (G.657.A2) 9/125 µm
-
Length10 m
-
ConnectorsSC/APC (8°) to SC/APC (8°)
-
Jacket MaterialLSZH (Low Smoke Zero Halogen)
-
Jacket ColorYellow
-
Cable Outer Diameter3 mm
-
Minimum Bend Radius> 30 mm
-
Maximum Data RateUp to 100 Gbit/s
-
ApplicationFTTH, FTTB, FTTx, ONT connections
-
Operating Wavelength (typical)1310 nm
-
Kink ProtectionYes
-
Operating Temperature Range-40°C to +85°C
-
Standards / SafetyIEC 60754-2, IEC 60332-1, IEC 61034
-
Return Loss / Insertion LossManufacturer measured low insertion loss and high return loss (quality performance)
Ratings
Description
Goobay singlemode fiber optic patch cable (OS2) 10 m with SC/APC (8°) to SC/APC (8°) connectors. Designed for FTTH, FTTB, FTTx installations and connection to Optical Network Terminals (ONT). Fiber: OS2 9/125 µm (G.657.A2). Jacket: LSZH (Low Smoke Zero Halogen), yellow. Cable outer diameter: 3 mm. Simplex construction. Supports high-speed transmission up to 100 Gbit/s. Minimum bend radius >30 mm. Kink protection provided. Operating temperature range -40°C to +85°C. Meets IEC 60754-2, IEC 60332-1 and IEC 61034 flammability/smoke standards. Manufacturer MPN: 59642, EAN: 4040849596421.
Technical Specifications
-
BrandGoobay
-
Model / MPN59642
-
SKU11.001.0026
-
EAN4040849596421
-
Product TypeFiber optic patch cord (simplex)
-
Fiber TypeSinglemode OS2 (G.657.A2) 9/125 µm
-
Length10 m
-
ConnectorsSC/APC (8°) to SC/APC (8°)
-
Jacket MaterialLSZH (Low Smoke Zero Halogen)
-
Jacket ColorYellow
-
Cable Outer Diameter3 mm
-
Minimum Bend Radius> 30 mm
-
Maximum Data RateUp to 100 Gbit/s
-
ApplicationFTTH, FTTB, FTTx, ONT connections
-
Operating Wavelength (typical)1310 nm
-
Kink ProtectionYes
-
Operating Temperature Range-40°C to +85°C
-
Standards / SafetyIEC 60754-2, IEC 60332-1, IEC 61034
-
Return Loss / Insertion LossManufacturer measured low insertion loss and high return loss (quality performance)
