The FNIRSI DS215H is a compact two-channel bench digital oscilloscope with 50 MHz bandwidth and a 250 MSa/s sample rate. It features a 3.5" IPS color display (480 × 320) and an integrated function generator supporting 13 waveform types with 0–50 kHz frequency range and 0.1–3.0 V amplitude. The unit...
More
Fnirsi Bench Oscilloscope DS215H 2-Channel 50 MHz 3.5" IPS
Product Code: 1167733788
Available in 4 - 6 days
108,23 €
or
3,38€ / month
εως 36 δόσεις με πιστωτική κάρτα
With the purchase of this product you earn 325 Bytes
Quantity:
Add
Need Help? Fill in your details so we can call you immediately!
Έως 36 Δόσεις. Δείτε το πλάνο δόσεων:
TBI Bank
Buy Now Pay Later.
4 installments 0% επιτόκιο, 20€ έως 300€
3 to 60 installments 300€ έως 100.00€
- 1. Ship with ACS Courier
- 2. Αποστολές με μεταφορικές εταιρίες για ογκώδη αντικείμενα
-
3. Pickup from BoxNow automated machine:
Με την BoxNow μπορείς να παραλάβεις το δέμα σου από Αυτόματο Μηχάνημα Παραλαβής που βρίσκεται κοντά σου, όλες τις ώρες της ημέρας 24/7. Η υπηρεσία έχει χρέωση 3€. Υπάρχει δυνατότητα αντικαταβολής με επιπλέον χρέωση 1€.
-
4. Pickup from the store:
Leof. El. Venizelou 73 (former Theseos), Kallithea
Συμπληρώστε τον ταχυδρομικό κωδικό για να λάβετε εκτίμηση τρόπου και κόστους μεταφορικών.
The FNIRSI DS215H is a compact two-channel bench digital oscilloscope with 50 MHz bandwidth and a 250 MSa/s sample rate. It features a 3.5" IPS color display (480 × 320) and an integrated function generator supporting 13 waveform types with 0–50 kHz frequency range and 0.1–3.0 V amplitude. The unit supports probe attenuation selection (1X/10X) and a maximum allowable input voltage of ±400 V (with appropriate probe configuration). Designed for portable bench use, it includes a built-in 1500 mAh battery and Type-C charging (5 V / 1 A). Dimensions: approx. 66 × 110 × 19.5 mm. Weight: approx. 138 g. Ideal for electronics measurements, education and hobbyist use.
-
BrandFnirsi
-
ModelDS215H
-
Product TypeBench Digital Oscilloscope (2 analog channels)
-
Channels2 (dual analog channels)
-
Bandwidth50 MHz
-
Maximum Sample Rate250 MSa/s
-
Vertical Sensitivity Range10 mV/div – 10 V/div
-
Maximum Input Voltage±400 V (with appropriate probe/attenuation)
-
Probe Attenuation1X / 10X selectable
-
Display Size3.5 inches
-
Display TypeIPS color
-
Display Resolution480 × 320 pixels
-
Function GeneratorBuilt-in function generator, supports 13 waveform types
-
Function Generator Frequency Range0 – 50 kHz
-
Function Generator Amplitude Range0.1 V – 3.0 V (peak-to-peak)
-
BatteryBuilt-in 1500 mAh rechargeable battery
-
Power / ChargingUSB Type-C charging, 5 V / 1 A
-
Dimensions (device)Approx. 66 x 110 x 19.5 mm
-
Product WeightApprox. 138 g
-
Housing / DesignCompact, lightweight portable bench design
-
Included InterfacesType-C charging port
-
UsageElectronics measurement, education, hobbyist and portable bench testing
Ratings
Description
The FNIRSI DS215H is a compact two-channel bench digital oscilloscope with 50 MHz bandwidth and a 250 MSa/s sample rate. It features a 3.5" IPS color display (480 × 320) and an integrated function generator supporting 13 waveform types with 0–50 kHz frequency range and 0.1–3.0 V amplitude. The unit supports probe attenuation selection (1X/10X) and a maximum allowable input voltage of ±400 V (with appropriate probe configuration). Designed for portable bench use, it includes a built-in 1500 mAh battery and Type-C charging (5 V / 1 A). Dimensions: approx. 66 × 110 × 19.5 mm. Weight: approx. 138 g. Ideal for electronics measurements, education and hobbyist use.
Technical Specifications
-
BrandFnirsi
-
ModelDS215H
-
Product TypeBench Digital Oscilloscope (2 analog channels)
-
Channels2 (dual analog channels)
-
Bandwidth50 MHz
-
Maximum Sample Rate250 MSa/s
-
Vertical Sensitivity Range10 mV/div – 10 V/div
-
Maximum Input Voltage±400 V (with appropriate probe/attenuation)
-
Probe Attenuation1X / 10X selectable
-
Display Size3.5 inches
-
Display TypeIPS color
-
Display Resolution480 × 320 pixels
-
Function GeneratorBuilt-in function generator, supports 13 waveform types
-
Function Generator Frequency Range0 – 50 kHz
-
Function Generator Amplitude Range0.1 V – 3.0 V (peak-to-peak)
-
BatteryBuilt-in 1500 mAh rechargeable battery
-
Power / ChargingUSB Type-C charging, 5 V / 1 A
-
Dimensions (device)Approx. 66 x 110 x 19.5 mm
-
Product WeightApprox. 138 g
-
Housing / DesignCompact, lightweight portable bench design
-
Included InterfacesType-C charging port
-
UsageElectronics measurement, education, hobbyist and portable bench testing
