Φις Ρεύματος ABL 100000039 Original SCHUKO & fr-be. Gummi (TPE). Black. IP44. Typ

The ABL 100000039 Original Stecker SCHUKO & fr-be Gummi (TPE) schwarz IP44 Typ 1506 is designed for versatility and durability, making it an essential component for various electrical applications. This robust male plug is tailored for both SCHUKO (CEE 7/7) and French/Belgian standards, ensuring...

Φις Ρεύματος ABL 100000039 Original SCHUKO & fr-be. Gummi (TPE). Black. IP44. Typ

Name: Φις Ρεύματος ABL 100000039 Original SCHUKO & fr-be. Gummi (TPE). Black. IP44. Typ
Brand: ABL
SKU: 1173623262
Price: 18.16 EUR
Availability: OutOfStock

Product Code: 1173623262

Available in 4 - 10 days

18,16 €

Quantity:

Add

Need Help? Fill in your details so we can call you immediately!

The ABL 100000039 Original Stecker SCHUKO & fr-be Gummi (TPE) schwarz IP44 Typ 1506 is designed for versatility and durability, making it an essential component for various electrical applications. This robust male plug is tailored for both SCHUKO (CEE 7/7) and French/Belgian standards, ensuring reliable performance in all conditions.

Key highlights include:

Material: Crafted from long-lasting TPE (thermoplastic elastomer), it resists UV exposure and other environmental factors.
Safety Features: The double earthing system provides enhanced safety, and it complies with several international standards.
Use Case: Ideal for heavy-duty applications, it performs well in both dry and damp environments.

Technical Specifications

Connection Type	Male plug (SCHUKO & fr-be)
Poles	2P + PE (2 cores + protective earth)
Nominal Voltage	250 V
Nominal Current	16 A
Max Conductor Size	3 × 2.5 mm²
Cable Diameter	6 - 12 mm
Sheath Stripping	33 - 35 mm
Core Stripping	8 - 10 mm

Connection type

Male plug (SCHUKO & fr-be)
Poles

2P + PE (2 cores + protective earth)
Nominal voltage

250 V
Nominal current

16 A
Max conductor size

3 × 2.5 mm²
Cable diameter

6 - 12 mm
Sheath stripping

33 - 35 mm
Core stripping

8 - 10 mm
Commodity code

85366990

Ratings

How do you rate this product?

0/5

Description

Key highlights include:

Material: Crafted from long-lasting TPE (thermoplastic elastomer), it resists UV exposure and other environmental factors.
Safety Features: The double earthing system provides enhanced safety, and it complies with several international standards.
Use Case: Ideal for heavy-duty applications, it performs well in both dry and damp environments.

Technical Specifications

Connection Type	Male plug (SCHUKO & fr-be)
Poles	2P + PE (2 cores + protective earth)
Nominal Voltage	250 V
Nominal Current	16 A
Max Conductor Size	3 × 2.5 mm²
Cable Diameter	6 - 12 mm
Sheath Stripping	33 - 35 mm
Core Stripping	8 - 10 mm

Technical Specifications

Connection type

Male plug (SCHUKO & fr-be)
Poles

2P + PE (2 cores + protective earth)
Nominal voltage

250 V
Nominal current

16 A
Max conductor size

3 × 2.5 mm²
Cable diameter

6 - 12 mm
Sheath stripping

33 - 35 mm
Core stripping

8 - 10 mm
Commodity code

85366990
