Eaton 9PX 5000i RT3U Netpack G2 (9PX5KIRTNG2)

Eaton 9PX 5000i RT3U Netpack G2 (9PX5KIRTNG2)

Name: Eaton 9PX 5000i RT3U Netpack G2 (9PX5KIRTNG2)
Brand: Eaton
SKU: 1153712587
Price: 5758.19 EUR
Availability: OutOfStock

Product Code: 1153712587

Upon Order

5.758,19 €

179,82€ / month

εως 36 δόσεις με πιστωτική κάρτα

With the purchase of this product you earn 17275 Bytes

Quantity:

Add

Need Help? Fill in your details so we can call you immediately!

Έως 36 Δόσεις. Δείτε το πλάνο δόσεων:

The Eaton 9PX 5000i RT3U Netpack G2 (9PX5KIRTNG2) is a 5000 VA / 5000 W on-line double-conversion UPS in a 3U rack/tower format. It features a hardwired input, 12 IEC outlets (6 x C13 + 6 x C19) plus a hardwired output, integrated Gigabit network card (SNMP v1/v3, IPv4/v6), graphical LCD with LED status bar, USB and RS232 ports, hot-swappable internal batteries and support for External Battery Modules (EBMs). It delivers high efficiency (up to ~96.7–97.2% in online mode), tight output regulation (±1%), low THDv (<1% on linear loads) and advanced battery management (ABM+, VRLA and Li-ion BMS support). Warranty: 3 years electronics (2 years battery; can extend to 3 years full upon registration).

Brand

EATON
Model

9PX 5000i RT3U Netpack G2
SKU / MPN

9PX5KIRTNG2
EAN

3553340710551
Category

Unterbrechungsfreie Stromversorgung (UPS)
Rated Power (VA)

5000 VA
Rated Power (W)

5000 W (nominal, 220–240 V)
Output Power (retailer reference)

4500 W (230 V, retailer data)
Topology

Online double-conversion (VFI) with Power Factor Correction (PFC)
Form Factor

3U Rack / Tower (19")
Dimensions (WxHxD)

482.6 mm x 132.6 mm (3U) x ~700 mm (approx.)
Weight (unit)

~47000 g (approx.)
Package Weight

~52000 g (approx.)
Input Connection

Hardwired / Fixed
Input Voltage (nominal)

230 V (supports 200/208/220/230/240 V)
Input Voltage Range

176–276 V (full load); 100–276 V (with derating)
Input Power Factor

>0.99
Input Frequency

50/60 Hz (auto-select), range 40–70 Hz
Output Voltage (nominal)

230 V (configurable 200/208/220/230/240 V)
Output Voltage Regulation

±1% (steady-state)
Output Waveform

Pure sine wave
Output THDv

<1% (linear load)
AC Outlets

6 x IEC C13, 6 x IEC C19 (plus 1 hardwired output)
Internal Bypass

Yes
Efficiency (online)

Up to ~96.7–97.2% (online mode)
Efficiency (battery)

~94% (battery mode)
Battery Type

Sealed lead-acid (VRLA); ABM+ management; Li-ion BMS supported
Battery Rating (internal)

12 V / 5 Ah (per battery module specification)
Battery Replaceable

Hot-swappable internal batteries; supports External Battery Modules (EBMs)
Network / Management

Gigabit Network Card included (SNMP v1/v3, IPv4/v6)
Communications Ports

Ethernet (Gigabit), USB (1), RS232 (1) – USB and RS232 cannot be used simultaneously
Auto-shutdown

Yes (software-supported)
LCD Display

Graphical LCD with LED status bar (multi-language)
Noise Level

~38 dB
Warranty

3 years electronics (2 years battery; 3 years full upon registration)
Certification / Energy

Energy Star qualified
Package Contents

UPS unit, 2 cable glands, 2 IEC-IEC output cables (1.2 m), USB cable (1.8 m), rack-mount kit
Special Features

Make-before-break bypass switching; high-density 3U design; increased power vs previous generation (~11%)

Ratings

How do you rate this product?

0/5

Description

Technical Specifications

Brand

EATON
Model

9PX 5000i RT3U Netpack G2
SKU / MPN

9PX5KIRTNG2
EAN

3553340710551
Category

Unterbrechungsfreie Stromversorgung (UPS)
Rated Power (VA)

5000 VA
Rated Power (W)

5000 W (nominal, 220–240 V)
Output Power (retailer reference)

4500 W (230 V, retailer data)
Topology

Online double-conversion (VFI) with Power Factor Correction (PFC)
Form Factor

3U Rack / Tower (19")
Dimensions (WxHxD)

482.6 mm x 132.6 mm (3U) x ~700 mm (approx.)
Weight (unit)

~47000 g (approx.)
Package Weight

~52000 g (approx.)
Input Connection

Hardwired / Fixed
Input Voltage (nominal)

230 V (supports 200/208/220/230/240 V)
Input Voltage Range

176–276 V (full load); 100–276 V (with derating)
Input Power Factor

>0.99
Input Frequency

50/60 Hz (auto-select), range 40–70 Hz
Output Voltage (nominal)

230 V (configurable 200/208/220/230/240 V)
Output Voltage Regulation

±1% (steady-state)
Output Waveform

Pure sine wave
Output THDv

<1% (linear load)
AC Outlets

6 x IEC C13, 6 x IEC C19 (plus 1 hardwired output)
Internal Bypass

Yes
Efficiency (online)

Up to ~96.7–97.2% (online mode)
Efficiency (battery)

~94% (battery mode)
Battery Type

Sealed lead-acid (VRLA); ABM+ management; Li-ion BMS supported
Battery Rating (internal)

12 V / 5 Ah (per battery module specification)
Battery Replaceable

Hot-swappable internal batteries; supports External Battery Modules (EBMs)
Network / Management

Gigabit Network Card included (SNMP v1/v3, IPv4/v6)
Communications Ports

Ethernet (Gigabit), USB (1), RS232 (1) – USB and RS232 cannot be used simultaneously
Auto-shutdown

Yes (software-supported)
LCD Display

Graphical LCD with LED status bar (multi-language)
Noise Level

~38 dB
Warranty

3 years electronics (2 years battery; 3 years full upon registration)
Certification / Energy

Energy Star qualified
Package Contents

UPS unit, 2 cable glands, 2 IEC-IEC output cables (1.2 m), USB cable (1.8 m), rack-mount kit
Special Features

Make-before-break bypass switching; high-density 3U design; increased power vs previous generation (~11%)
