D-Link DES-1008C/E 8-Port Fast Ethernet Unmanaged Desktop Switch

Description

Technical Specifications

• Brand
  D-Link
• Model
  DES-1008C/E (DES-1008C family)
• Product Type
  8-Port Fast Ethernet Unmanaged Desktop Switch
• Ports
  8 x 10/100Base-TX auto-sensing RJ-45
• Port Features
  Auto MDI/MDIX on all ports
• Switching Capacity
  1.6 Gbps
• Maximum Forwarding Rate
  1.19 Mpps
• MAC Address Table
  2,000 entries
• Packet Buffer
  96 KB
• Jumbo Frame Support
  Up to 2048 bytes
• Transmission Method
  Store-and-forward
• Flow Control
  IEEE 802.3x
• Energy Efficiency
  IEEE 802.3az Energy Efficient Ethernet (D-Link Green)
• Cooling
  Fanless (silent operation)
• Power Input
  DC 5V, 0.55A
• Maximum Power Consumption
  Approximately 1.55 W
• Standby Power Consumption
  Approximately 0.55 W
• Maximum Heat Dissipation
  Approximately 0.691 BTU/h
• MTBF
  ~1,579,582 hours
• Dimensions
  131 × 54 × 21 mm
• Product Weight
  742 g
• Operating Temperature
  0 to 40 °C
• Storage Temperature
  -40 to 70 °C
• Operating Humidity
  10% to 90% RH
• Storage Humidity
  5% to 95% non-condensing
• Use Case
  SOHO and small business wired network expansion, plug-and-play deployments
• Package Contents
  Switch unit, power adapter (DC 5V), quick install guide
